Configuring Network Interfaces 24
Configuring Protocols
Follow these steps to configure the protocols:
1. From the Internetworking Configuration menu, select Protocols.
2. The list of available protocols displays. Select TCP/IP or other protocols as needed. Press Enter.
3. The configuration screen for the protocol you have selected displays. Modify the values as needed.
4. Press Esc to exit the configuration screen.
5. If NetWare 4.x, select Yes and press Enter when you are queried to save your changes. If NetWare 5, save
your changes.
6. Repeat this process for each protocol to be configured. When done, press Esc to exit to the
Internetworking Configuration menu.
Configuring WAN Call Destinations
Follow these steps to create WAN Call Destinations:
1. From the Internetworking Configuration menu, select WAN Call Directory. The list of Configured WAN Call
Destinations displays.
2. Press Insert to create an entry.
3. Enter the New Call Destination Name and press Enter.
4. Select one supported wide-area medium (for example, PPP) and press Enter. The PPP Call Destination
Configuration screen displays.
5. Move the cursor to the Interface Name field and press Enter. The list of PPP Network Interfaces displays.
6. Select the desired port by name and press Enter.
7. Select Telephone Number and enter the target server’s telephone number.
8. Set authentication and other parameters on the PPP Call Destination Configuration screen as needed. If
authentication is enabled, you must enter a password in order to save your changes.
9. When you are done, press Esc to exit. You are asked if you want to save your changes. Select Yes and press
Enter.
The updated list of WAN Call Destinations displays.
10. Repeat Steps 2–9 to add more destinations as needed, or press Esc to exit to the Internetworking
Configuration menu.
