E01-11040
STORE NAME /MESSAGE AND COMMERCIAL MESSAGE
PROGRAMMING OR CHANGING (Submode 1)
Mode Lock: SET / GT Lock: Neutral
1 [©/FOR]
Repeat for other line.
1_
Submode No.
-► I Line No.
I
[ST] ----------------------------
1 to3
O'' (See NOTE 2 below.)
1 to 7
Character Entries
{Max. 20 characters for each
line; see CHARACTER
ENTRIES, on page 36.)
[ST]
“► [AT/TL]
Indicates the end of a line.
{Any unprogrammed parts of a line end will be
filled with blanks.)
For sequentially programming lines, the tine number specification can be skipped.
NOTES: 1. For each
//ne, a
maximum of 20 regular-sized characters or 10 double-sized
characters may be entered. A combination of both types is also available.
2. If the option
“Store
Name Print by RUBBER STAMP** is selected, no data can be
programmed for the store name/message. Therefore, enter 1 to 3 as Line No.
for the commercial message data only.
If the option
“Store
Name Print by DOT PRINTER’* is selected, use 1 through 4
for the store name/message and 5 through
7
for the commercial message data,
as Une No.
3. If no commercial message is required on the receipt, program blanks for all three
lines. As a result no extra lines will be fed. If any one of the three lines is
programmed, the two other lines will cause line feeds.
4. The 4-line range assigned for the store name/message will be either printed or
fed, as long as the option ’’Store Name print by DOT PRINTER** is selected.
5. If any incorrect characters have been programmed, depress the [C] key to clear
all the characters on a line and then re-enter characters from the beginning, or
end the line with an [ST] and re-program the entire line. The new data will be
active.
6. When all the lines have been programmed, do a check by issuing a receipt.
Only the tines with errors need to be re-programmed; other tines will not be
affected.
4 3
