30
> ‘MENU’ + “MAP PRESENTATION” + ‘ENTER’
The default setting is generic. See paragraph 3.6 for further details.
3.5.8 Automatic Information
The display of Automatic Information is controlled by this setting. The category of detail selected
will be displayed on the Moving Map automatically when the cursor is placed over the object.
> ‘MENU’ + “AUTOMATIC INFO” + ‘ENTER’
The selection options are: OFF/AERO+TERREST /AERONAUTICAL/TERRESTRIAL/MARINE (refer
to Par. 3.3). If the category is turned Off, no details about objects will be displayed automatically.
(Full Info is can be viewed from the Cursor Menu.) The default setting is Aero + Terrest.
3.5.9 Rangerings
Range rings, 30 degrees radials, added cross at rings center is selectable in TRACK_UP or COURSE_
UP mode, in the Fix position for increased Pilot Awareness.
3.5.10 vfr, Airspace, Land, Marine And other Settings
The following menus enable/disable the display of categories of data.
> ‘MENU’ + “VFR/AIRSPACE/LAND/MARINE/OTHER SETTINGS” + ‘ENTER’
3.5.10.1 vFR Settings
The VFR Settings category relates to the aviation features found in the Navdata Compact Flash.
Airports
:
ON/OFF. The default setting is On.
voR
:
ON/OFF. The default setting is On.
ndB
:
ON/OFF. The default setting is On.
Intersections
:
ON/OFF. The default setting is On.
vertical obstructions
:
ON/OFF. The default setting is On.
Aero objects Id
:
OFF/SMALL/MEDIUM/LARGE. The default setting is Large.
enroute Communications
:
ON/OFF. The default setting is On.
Note
The VFR Reporting points can be used as Route waypoints.
3.5.10.2 Airspace Settings
IThe Airspace Settings category relates to the airspace data found in the Navdata Compact Flash.
Low Airways: ON/OFF. The default setting is Off.
Note
Low Airways are only displayed below 50 Nm.
The Airline Airway, Control Airway and Direct Route Airway are displayed below 5 Nm.
This is the default setting. It is also possible to select them in the 50 Nm, 0 Nm, 10 Nm map scales.
The Official Designated Airway and RNAV Airway are displayed below the 50 Nm map scale.
To change from default settings, select ‘MENU’ + ‘SELECTIVE DISPLAY’, and scroll-down to any
of the following:
1. Airline Airway
. Control Airway
3. Direct Route Airway
