17
presentations and quickly filter mapping information on the display.
‘CYCLE’: selects the Cycle mode
There are three Cycle modes and holding the Cycle Key one to three times activates them. The
Cycle Key is defaulted in the Cycle 1 position that normally activates all features to be visible on the
display. By holding the Cycle Key once, Cycle is activated and holding it a second time activates
Cycle 3, one last Cycle key activation and the display is back to Cycle 1.
To set user preferences for the Cycle Key:
>‘MENU’ + “SELECTIVE DISPLAY” + ‘ENTER’
‘CYCLE’ 1 sec: select the Map Presentation Menu
The menu enables the user to select between generic representation mode, three TAWS modes
(auto, low sep and high sep) and two Weather modes (North America only)
The Cycles appear in the first three columns and are labeled 1, and 3. In order to adjust at which
Cycle features appear, use the Cursor Control key to highlight an item and hit ‘ENTER’ to remove
the item from appearing. Hit ENTER again to check the item so that it will appear on the display
when that Cycle is activated. Continue to use this procedure to activate features in Cycles 1 - 3 as
desired.
The indication of the current de-clutter CYCLE is displayed on the data window scale and north
indicator field.
2.2 tURnInG the ekP-Iv on/oFF
Before powering On the EKP-IV, check for the correct voltage (10-35 Volt DC).
2.2.1 turning on
Press and hold ‘POWER’ for 1 second. The EKP-IV emits one rapid beep sound and a Title page
containing information about the Product name, Software version, library version and cartridges
installed is displayed. This data can also be viewed in the “About” page in the “Main Menu”.
