36
7.3.4 Other Application
The software utility will show you at least 32 units Device ID and Name. You can click the
Console down list to select which device that you want to configure output /input values.
The entire connected Device name will be showed on the Console List as Figure 7-14.
For this model, the software utility will show at least 1 up to 32 devices. The example as
below shows you an ID: 0 for the Name: MRM-602P Switcher presently.
 When the Console List is empty, please pay attention to the location of switcher pin
on the rear panel of Device is correctly. Then, click Scan to research the configured.
Figure 7-14 Other Application
