ECS and CXT-E Retrofit Instructions Kit # 27004-TAB
Technical Instruction Document
TID-0141_0A
12/30/2014
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 Page 75 of 76
TABLE D-2. VALVE KITS FOR PREVIOUSLY INSTALLED SELF-CONTAINED ACTUATOR
(FOR VALVE SIZES FROM 2.50” TO 4.00”)
VALVE SIZE AND PART NUMBERS
ITEM
QTY
PART NAME
2.50 INCH
3.00 INCH
4.00 INCH
1
1
ACTUATOR
69170
69170
69170
2
1
LINKAGE
24038-1
24038-1
24038-2
3
1
GASKET
81046
81046
81046
4
2
3/8-16 x 5/8” LG. CAP SREWS
54014
54014
54014
5
1
SCALE
59028-2.50
59028-3
59028-4
6
2
8-32 HEX NUT
123332
123322
123322
7
2
1/4-20 NUT
6-226
6-226
N/A
8
2
3/8-16 HEX NUT
N/A
N/A
6-264
9
1
PACKING ASSY
121567
121568
121568
10
1
VALVE TOP GASKET
122083
122204
122203
11
1
VALVE TOP
18781
18823
18824
12
1
LOWER SHAFT
122223
122230
122224
13
1
PACKING NUT
122664
122665
122665
14
2
HEX HEAD PLUG, 1/4”
9-22
9-22
9-22
15
4
CAP SCREW, 1/2-13 x 1-1/4”
6-24
N/A
N/A
16
4
CAP SCREW, 5/8-11 x 1-1/2”
N/A
6-310
6-310
17
1
MAIN VALVE ASSEMBLY KIT
27006-2.50
27006-3.00
27006-4.00
--- END ---
