AERCO CXT-E Retrofit Kit User Manual
Page 69

ECS and CXT-E Retrofit Instructions Kit # 27004-TAB
Technical Instruction Document
TID-0141_0A
12/30/2014
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 Page 69 of 76
TABLE B-3. COMPOUND PRESSURE GAUGE OPTIONS (Table B-1, Item 2)
AERCO
PART NO.
QTY
PRESSURE RANGE
8356-15
1
30” Vacuum to 15 ps1/kPa
8356-30
1
30” Vacuum to 30 ps1/kPa
8356-60
1
30” Vacuum to 60 ps1/kPa
8356-100
1
30” Vacuum to 100 ps1/kPa
8356-150
1
30” Vacuum to 150 ps1/kPa
TABLE B-4. VALVE FLANGE GASKET OPTIONS (Table B-1, Item 3)
AERCO
VALVE
PART NO.
DESCRIPTION
FLANGE GASKET
PART NO.
FLANGE
GASKET
QTY
24036-1.00
1” CXT-E Control Valve
N/A
None
24036-1.25
1-1/4” CXT-E Control Valve
N/A
None
24036-1.50
1-1/2” CXT-E Control Valve
N/A
None
24036-2.00
2” CXT-E Control Valve
N/A
None
24036-2.50
2-1/2” CXT-E Control Valve
4-52
2
24036-3.00
3” CXT-E Control Valve
4-55
2
24036-4.00
4” CXT-E Control Valve
4-58
2
