AERCO CXT-E Retrofit Kit User Manual
Page 56
ECS and CXT-E Retrofit Instructions Kit # 27004-TAB
Technical Instruction Document
TID-0141_0A
12/30/2014
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 Page 56 of 76
-E
-
OFF
POWER ON
CXT-E
ACTUATOR
LINKAGE
ASSY
CONTROL
VALVE
ECS
CONTROL
BOX
MOUNTING
BRACKET
STEAM IN
SIDE VIEW
COMPOUND
PRESSURE
GAUGE
SOLENOID
VALVE
HOT WATER
OUTLET
Figure 5-1. B-Plus Package Water Heater With ECS Control System & CXT-E
Control Valve
(Sheet 2 of 2)
