Figure 2-10. control box with door open – AERCO CXT-E Retrofit Kit User Manual
Page 23
ECS and CXT-E Retrofit Instructions Kit # 27004-TAB
Technical Instruction Document
TID-0141_0A
12/30/2014
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 Page 23 of 76
SHELL OUTLET
°F
PSIG
STEAM PRESS.
CALIBRATED CONTROLLER
ADJUST SETPOINT DIAL
TO DESIRED TEMPERATURE
ONLY
REFER TO MANUAL AC-103
FOR MAINTENANCE INSTRUCTIONS
PT.NO.123151
MOUNTING
BRACKET
(SAVE)
8-32 x 3/8" LG.
SCREWS (QTY=6)
MOUNTING
BRACKET
SCREW
CONTROL BOX USED WITH PNEUMATIC CONTROL VALVE
REAR
MOUNTING
PANEL
TOP
MOUNTING
BRACKET
SCREW
REAR
MOUNTING
PANEL
Figure 2-10. Control Box With Door Open
