ECS and CXT-E Retrofit Instructions Kit # 27004-TAB

Technical Instruction Document

TID-0141_0A

12/30/2014

AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 Page 20 of 76

ACTUATOR
CONNECTING
SHAFT

ACTUATOR

HOUSING

VALVE

BODY

VALVE STEM

TOP PISTON

BOTTOM

PISTON

HOLE

VALVE SEAT

RETAINING

DISC

CAP SCREWS
(4)

VALVE SEAT

Figure 2-7. Self-Contained Control Valve Actuator Removal – 2 ½” to 4”

ACTUATOR
CONNECTING
SHAFT

HOLE

VALVE STEM

RETAINING

NUT

VALVE PLUG
SHAFT

VALVE

BODY

Figure 2-8. Self-Contained Control Valve Actuator Removal – 1” to 2”
