Carrier 48AJ - Manual (Page 39)

39
Table 8 — Electrical Data — 48EJ,EK,EW,EY Units
See Legend and Notes on page 42.
UNIT
SIZE
48EJ,EK,
EW,EY
NOMNAL
VOLTAGE
(3 Ph,
60 Hz)
VOLTAGE
RANGE
COMPRESSOR
OFM IFM
POWER
EXHAUST
COMBUSTION
FAN MOTOR
POWER SUPPLY
No. 1 No. 2
Min Max RLA LRA RLA LRA Qty Hp
FLA
(ea)
Hp FLA FLA LRA FLA MCA MOCP*
024
208/230 187 254 39.1 228 25.6 160 2 1 5.3
5
16.7/
15.2
— — 0.96 101.8/100.3 125/125
23.6 41.6 0.96 125.4/123.9 150/150
10
30.8/
28.0
— — 0.96 115.9/113.1 150/150
23.6 41.6 0.96 139.5/136.7 175/175
15
46.2/
42.0
— — 0.96 131.3/127.1 150/150
23.6 41.6 0.96 154.9/150.7 175/175
460 414 508 19.9 114 11.5 80 2 1 2.7
5 7.6
— — 0.5 49.4 60
12.6 23.6 0.5 62.0 80
10 14.0
— — 0.5 55.8 70
12.6 23.6 0.5 68.4 80
15 21.0
— — 0.5 62.8 80
12.6 23.6 0.5 75.4 90
575 518 632 16.0 91 9.6 64 2 1 2.4
5 6.1
— — 0.5 40.5 50
12.6 23.6 0.5 53.1 60
10 11.0
— — 0.5 45.4 60
12.6 23.6 0.5 58.0 70
15 17.0
— — 0.5 51.4 60
12.6 23.6 0.5 64.0 80
028
208/230 187 254 39.1 228 39.1 228 2 1 5.3
7.5
24.2/
22.0
— — 0.96 122.8/120.6 150/150
23.6 41.6 0.96 146.4/144.2 175/175
10
30.8/
28.0
— — 0.96 129.4/126.6 150/150
23.6 41.6 0.96 153.0/150.2 175/175
15
46.2/
42.0
— — 0.96 144.8/140.6 175/175
23.6 41.6 0.96 168.4/164.2 200/200
460 414 508 19.9 114 19.9 114 2 1 2.7
7.5 11.0
— — 0.5 61.2 80
12.6 23.6 0.5 73.8 90
10 14.0
— — 0.5 64.2 80
12.6 23.6 0.5 76.8 90
15 21.0
— — 0.5 71.2 90
12.6 23.6 0.5 83.8 100
575 518 632 16.0 91 16.0 91 2 1 2.4
7.5 9.0
— — 0.5 49.8 60
12.6 23.6 0.5 62.4 70
10 11.0
— — 0.5 51.8 60
12.6 23.6 0.5 64.4 80
15 17.0
— — 0.5 57.8 70
12.6 23.6 0.5 70.4 80
030
208/230 187 254 57.1 266 39.1 228 2 1 5.3
10
30.8/
28.0
— — 0.96 151.9/149.1 200/200
23.6 41.6 0.96 175.5/172.7 225/225
15
46.2/
42.0
— — 0.96 167.3/163.1 225/225
23.6 41.6 0.96 190.9/186.7 225/225
20
59.4/
54.0
— — 0.96 180.5/175.1 225/225
23.6 41.6 0.96 204.1/198.7 250/250
460 414 508 25.6 120 19.9 114 2 1 2.7
10 14.0
— — 0.5 71.3 90
12.6 23.6 0.5 83.9 100
15 21.0
— — 0.5 78.3 100
12.6 23.6 0.5 90.9 110
20 27.0
— — 0.5 84.3 100
12.6 23.6 0.5 96.9 110
575 518 632 20.5 96 16.0 91 2 1 2.4
10 11.0
— — 0.5 57.4 70
12.6 23.6 0.5 70.0 90
15 17.0
— — 0.5 63.4 80
12.6 23.6 0.5 76.0 90
20 22.0
— — 0.5 68.4 80
12.6 23.6 0.5 81.0 100
