Table 7 — Electrical Data — 48AJ,AK,AW,AY Units
LEGEND
*Fuse or HACR circuit breaker per NEC.
NOTES:
1. In compliance with NEC requirements for multimotor and combi-
nation load equipment (refer to NEC Articles 430 and 440), the
overcurrent protective device for the unit shall be fuse or HACR
breaker. The Canadian units may be fuse or circuit breaker.
2. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply volt-
age is greater than 2%. Use the following formula to determine
the percent of voltage imbalance.
% Voltage imbalance
Example: Supply voltage is 460-3-60.
AB = 452 v
BC = 464 v
AC = 455 v
= 457
Determine maximum deviation from average voltage.
(AB) 457 – 452 = 5 v
(BC) 464 – 457 = 7 v
(AC) 457 – 455 = 2 v
Maximum deviation is 7 v.
Determine percent of voltage imbalance.
% Voltage Imbalance = 100 x
= 1.53%
This amount of phase imbalance is satisfactory as it is below the
maximum allowable 2%.
UNIT SIZE
48AJ,AK,
AW,AY
NOMINAL
VOLTAGE
(3 PH, 60 Hz)
VOLTAGE RANGE
COMPRESSOR
OFM
IFM
POWER
EXHAUST
POWER
SUPPLY
No. 1
No. 2
Min
Max
RLA LRA RLA LRA Qty FLA Hp
FLA
FLA
(total)
MCA
MOCP*
020
208/230
187
253
39.1
228
25.6
160
2
5.3
(ea)
5
16.7/15.2
—
101.8/100.3
125/125
23.6/23.6
125.4/123.9
150/150
10
30.8/28.0
—
115.9/113.1
150/150
23.6/23.6
139.5/136.7
175/175
15
46.2/42.0
—
133.1/127.8
175/150
23.6/23.6
156.7/151.4
200/175
460
414
508
19.9
114
11.5
80
2
2.7
(ea)
5
7.6
—
49.4
60
12.6
62.0
80
10
14
—
55.8
70
12.6
68.4
80
15
21
—
63.1
80
12.6
75.7
90
575
518
632
16
91
9.6
64
2
2.4
(ea)
5
6.1
—
40.5
50
12.6
53.1
60
10
11
—
45.4
60
12.6
58.0
70
15
17
—
51.7
60
12.6
64.3
80
025
208/230
187
253
39.1
228
39.1
256
2
5.3
(ea)
7.5
24.2/22.0
—
122.8/120.6
150/150
23.6/23.6
146.4/144.2
175/175
10
30.8/28.0
—
129.4/126.6
150/150
23.6/23.6
153.0/150.2
175/175
15
46.2/42.0
—
146.6/141.3
175/175
23.6/23.6
170.2/164.9
200/200
460
414
508
19.9
114
19.9
114
2
2.7
(ea)
7.5
11
—
61.2
80
12.6
73.8
90
10
14
—
64.2
80
12.6
76.8
90
15
21
—
71.5
90
12.6
84.1
100
575
518
632
16
91
16
91
2
2.4
(ea)
7.5
9
—
49.8
60
12.6
62.4
70
10
11
—
51.8
60
12.6
64.4
80
15
17
—
58.1
70
12.6
70.7
80
FLA
— Full Load Amps
HACR — Heating, Air Conditioning and Refrigeration
IFM
— Indoor (Evaporator) Fan Motor
LRA
— Locked Rotor Amps
MCA — Minimum Circuit Amps
MOCP— Maximum Overcurrent Protection
NEC — National Electrical Code
OFM — Outdoor (Condenser) Fan Motor
RLA
— Rated Load Amps
= 100 x
max voltage deviation from average voltage
average voltage
Average Voltage =
452 + 464 + 455
3
=
1371
3
IMPORTANT: If the supply voltage phase imbalance is
more than 2%, contact your local electric utility company
immediately.
