CHAPTER 3: CONTROL PANEL OPERATION
Page 34 of 160 PR2: 04/22/13
Benchmark 2.0LN Dual-Fuel Low NOx Boiler
Operation and Maintenance Manual
OMM-0052_0E
GF-127
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288
3.6 CONFIGURATION MENU
The Configuration Menu shown in Table 3-4 permits adjustment of the Internal Setpoint
(Setpt) temperature regardless of whether the valid password has been entered. Setpt is
required for operation in the Constant Setpoint mode. The remaining options in this menu
require the valid password to be entered, prior to changing existing entries. This menu
contains a number of other configuration settings which may or may not be displayed,
depending on the current operating mode setting.
NOTE
The Configuration Menu settings shown in Table 3-4 are
Factory-Set in accordance with the requirements
specified for each individual order. Therefore, under
normal operating conditions, no changes will be required.
Table 3-4: Configuration Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Internal Setpt Lo Temp Limit Hi Temp Limit 130°F
Unit Type
KC Boiler, KC Boiler LN,
BMK Boiler Std, BMK Boiler LN,
BMK Blr Std Dual, BMK Blr LN KC Water
Heater,
KC Wtr Heater LN,
Innovation WH
BMK Boiler Dual
Unit Size
600 MBH, 750 MBH, 800 MBH 1000 MBH,
1060 MBH,
1500 MBH, 2000 MBH,
3000 MBH
2000 MBH
Fuel Type Natural Gas, Propane Natural Gas
Boiler Mode
Constant Setpoint, Remote Setpoint,
Direct Drive, Combination
Outdoor Reset
Constant Setpoint
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Remote Signal
(If Mode = Remote Setpoint, Direct
Drive or Combination)
4 – 20 mA/1 – 5V
0 -20 mA/0 – 5V
PWM Input (BMS)
Network
4 – 20 mA,
1-5V
Bldg Ref Temp
(If Mode = Outdoor Reset)
40°F 230°F 70°F
Reset Ratio(If Mode =
Outdoor Reset)
0.1 9.9 1.2
Outdoor Sensor Enabled or Disabled Disabled
System Start Tmp
(If Outdoor Sensor-
Enabled) 30°F 100°F 60°F
Setpt Lo Limit 40°F Setpt Hi Limit 60°F
Setpt Hi Limit Setpt Lo Limit 195°F 195°F
Temp Hi Limit 40°F 210°F 195°F
Max Valve Position 40% 100% 100%
