KEYENCE IV-M30 User Manual
Iv-m30, Intelligent monitor, Instruction manual

1
IV Series (Monitor) - IM_E
Intelligent monitor
IV-M30
Instruction Manual
Read this manual before using the product in order to
achieve maximum performance.
Keep this manual in a safe place after reading it so that it
can be used at any time.
For details of functions, refer to the IV Series User's Manual
(Monitor).
y
The IV Series User's Manual can be downloaded from the
KEYENCE web site:
http://www.keyence.com/
Symbols
The following symbols alert you to important messages.
Be sure to read these messages carefully.
It indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
It indicates a hazardous situation which, if
not avoided, could result in death or serious
injury.
It indicates a hazardous situation which, if not
avoided, could result in minor or moderate
injury.
It indicates a situation which, if not avoided,
could result in product damage as well as
property damage.
It indicates cautions and limitations that must
be followed during operation.
It indicates additional information on proper
operation.
It indicates tips for better understanding or useful
information.
Cautions
(1) Unauthorized reproduction of this manual in whole or
part is prohibited.
(2) The contents of this manual may be changed for
improvements without prior notice.
(3) An utmost effort has been made to ensure the contents of
this manual are as complete as possible. If there are any
mistakes or questions, please contact a KEYENCE office
listed in the back of the manual.
(4) Regardless of item (3), KEYENCE will not be liable for
any effect resulting from the use of this unit.
(5) Any manuals with missing pages or other paging faults
will be replaced.
The company names and product names used in this
manual are registered trademarks or the trademarks of their
respective companies.
Safety Information for IV-M30
General Precautions
y
Do not use this product for the purpose to
protect a human body or a part of human body.
yThis product is not intended for use as an explosion-
proof product. Do not use this product in a hazardous
location and/or potentially explosive atmosphere.
yYou must verify that the IV Series are operating
correctly in terms of functionality and performance
before the start and the operation of the IV Series.
y
We recommend that you take substantial
safety measures to avoid any damage in the
event of a problem occurring.
yKEYENCE never warrants the function or performance
of the IV-M30 if it is used in manner that differs from
the IV-M30 specifications contained in this instruction
manual or if the IV-M30s are modified by yourself.
y
When the IV-M30 is used in combination with
other instruments, functions and performance
may be degraded, depending on operating
conditions and the surrounding environment.
y
Do not place the instruments, including
peripherals, under rapid temperature
change. It may cause condensation and may
damage instruments or peripherals.
y
Remove the power cable from the power supply
if you do not use IV-M30 for a long time.
Important Instructions
Observe the following precautions to prevent malfunction of
the IV Series and to ensure that it is used properly.
Precautions on use
yThe power of the IV-M30 and instruments
connected to IV-M30 must be turned off when the
cable is to be installed or removed. Failure to do so
may cause an electric shock or a product damage.
y
Use the IV-M30 in the correct supply voltage.
Failure to do so may cause product damage.
y
For instructions
y
Do not turn OFF the power while setting
the items or saving the settings. Otherwise,
all or part of the setting data may be lost.
y
The enclosure rating of the monitor (IV-M30)
is IP40. As it is not waterproof, be careful
when handling it.
yWhen the IV-M30 becomes dirty, do not rub it with
a wet cloth, benzene, thinner, or alcohol. Doing
so may change the color or shape of the unit.
yIf the unit is heavily contaminated, disconnect
all the cables including the power supply cable,
wipe off the dirt with a cloth soaked with mild
detergent, and then wipe with a soft dry cloth.
y
LCD panel
yDo not press the touch panel with the tip of your
nail or anything that has a sharp tip such as a pen
or a screwdriver. Doing so may cause damage.
yDo not apply shock to the touch panel or press it
with excessive force. Doing so may cause damage.
yThe LCD panel may have some dots that are always
lit (bright dots) or ones that are always unlit (black
dots). This phenomenon is not a problem.
y
Due to the unique characteristics of an
LCD, displaying the same image for a long
time may cause an afterimage.
y
USB memory
y
Use products recommended by KEYENCE.
y
A USB memory device with a security
function cannot be used.
y
Unplug the USB memory when turning on
or off the power of IV-M30.
yDo not remove the USB memory while the USB
is being written on. Otherwise, all or part of the
setting data may be lost or it may cause damage.
Measures to be taken when an abnormality occurs
In the following cases, turn the power OFF
immediately. Using the IV Series in an abnormal
condition could cause fire, electric shock, or
malfunction. Contact our office for repair.
y
If water or debris enters the IV Series.
yIf the IV Series is dropped or the case is damaged.
y
If abnormal smoke or odor emanates from
the IV Series.
96M12231
