XG-8800(P)/8802(P)/8800L(P)/8802L(P)
*1 For the type where a P is added to the end of the main unit, it will become a PNP Open Collector.
*2 Models equipped with the Ethernet port in the CPU unit support Ethernet port direct connection.
*3 When Camera 1 to 6 are in use, up to 2 high speed cameras (CA-H****/XG-H***) can be connected (to Camera 3 and 4). When Camera 1 to 8 are in use, high speed cameras cannot be used.
Model type XG-8800/8802 XG-8800L/8802L
Pixels
• With XG-H500C/H500M connected 5 mega-pixel mode: 2432(H) x
2050(V), approx. 4.99 mega-pixels
• With XG-200C/S200C/H200C/200M/S200M/H200M connected
2 mega-pixel mode: 1600(H) x 1200(V), approx. 1.92 mega-pixels
1 mega-pixel mode: 1024(H) x 960(V), approx. 980,000 pixels
• With XG-H100C/H100M connected 1000(H) x 1000(V), 1 mega-pixel
• With XG-035C/S035C/H035C/035M/S035M/H035M connected
310 k pixel mode: 640(H) x 480(V), approx. 310,000 pixels
240 k pixel mode: 512(H) x 480(V), approx. 240,000 pixels
• With XG-HL02M is connected: 2048(H) x 16384(L), approx. 33.55
mega-pixels
• With XG-H500C/H500M connected 5 mega-pixel mode: 2432(H) x
2050(V), approx. 4.99 mega-pixels
• With XG-200C/S200C/H200C/200M/S200M/H200M connected
2 mega-pixel mode: 1600(H) x 1200(V), approx. 1.92 mega-pixels
1 mega-pixel mode: 1024(H) x 960(V), approx. 980,000 pixels
• With XG-H100C/H100M connected 1000(H) x 1000(V),
1 mega-pixel
• With XG-035C/S035C/H035C/035M/S035M/H035M connected
310 k pixel mode: 640(H) x 480(V), approx. 310,000 pixels
240 k pixel mode: 512(H) x 480(V), approx. 240,000 pixels
Camera input
• When the CA-EC80 (Standard equipment) and XG-EC80 is equipped:
2 color/monochrome Area Scan Cameras (for the XG-H500C/200C/
S200C/H200C/H100C/035C/S035C/H035C/H500M/200M/S200M/
H200M/H100M/035M/S035M/H035M, mixed connection possible)
• When the CA-EC80/XG-EC80 is equipped, 2 extra cameras (8
cameras maximum when 4 units are equipped) can be connected. *3
When the XG-EC80 is equipped, up to 2 Area Scan Camera
expansion units (maximum 8 cameras) can be connected.
• When the CA-EC80L (Standard equipment) and XG-EC80 is
equipped: 1 monochrome Line Scan Camera (for the CA-HL02M)
• When the CA-EC80/XG-EC80 is equipped: 2 color/monochrome Area
Scan Cameras (for the XG-H500C/200C/S200C/H200C/H100C/
035C/S035C/H035C/H500M/200M/S200M/H200M/H100M/035M/
S035M/H035M, mixed connection is possible)
*3
• When the CA-EC80L/XG-EC80L is equipped, 1 Line Scan Camera
expansion unit (maximum 4 cameras) can be connected, and when
the CA-EC80/XG-EC80 is equipped, up to 2 Area Scan Camera
expansion units (maximum 8 cameras) can be connected. (mixed
connection is possible)
Trigger input Simultaneous capture by up to 8 cameras/individual capture can be selected.
Main image processor DSP (High-speed)
Registered number of inspection settings SD cards 1 and 2 can each hold 1000 programs (depending on the size of the SD card and the size of the programs), external switching possible
Number of registered screens
Maximum 1000 screens for each program (depending on SD card size),Image compression also available.
Image registration of position adjustment images and partial image registration available. External switching possible based on variable reference.
SD card
• SD card slot x 2 (SDHC compatible)
• Compatible with OP-87133 (512MB), CA-SD1G (1GB: installed standard to SD1), and CA-SD4G (4GB: SDHC)
Interface
Controlled input (compatible with
arbitrary assignment)
• 26 inputs (including eight high speed inputs designed for trigger
input)
• Input rating 26.4 V or lower, 2 mA or greater (3 mA or greater for high
speed input terminal)
• 20 inputs (including four high speed inputs designed for trigger input)
• Input rating 26.4 V or lower, 2 mA or greater (3 mA or greater for high
speed input terminal)
Controlled output (compatible with
arbitrary assignment) • 32 outputs (including eight high speed outputs designed for FLASH outputting linked to external device)
• NPN open collector
*1 Maximum 50 mA (30 V or less)
Encoder input
For the Open Collector Output (Dedicated to 24 V outputs) using the
Control Input Terminal. (2 systems) For the Open Collector Output (Dedicated to 24 V outputs) using the
RS-422 Line Driver Output Terminal and Control Input Terminal.
(Choose each system or for the open collector output, choose two
systems.)
Monitor output Analog RGB Output, XGA (1024 x 768, 24 bit color)/SVGA (800 x 60, 24 bit color) Switch (can be set by the inspection settings unit)
Operation indicators LED display for Power ON, Operation and ERROR
RS-232C
2 Port up to Maximum baud rate of 230400 bps
The digit output or control input/output and CA Series Touch Panel interface can be switched.
PLC link
• Numerical value output and control input/output using the RS-232C port or Ethernet port enabled. (Do not use to connect to CC-Link, EtherNet/IP
and PROFINET.)
• Following PLCs are supported via link unit: *2
KEYENCE: KV-700 Series, KV-1000 Series, KV-3000 Series, KV-5000 Series, KV-5500 Series, KV Nano Series
Mitsubishi Electric: MELSEC A Series (RS-232C only), Q Series, L Series
OMRON: SYSMAC C Series (RS-232C only), CP1/CS1/CJ1/CJ2 Series
YASKAWA Electric: MP900 Series (RS-232C only), MP2000 Series
Ethernet
• Numerical value output, and control input/output enabled.
• By the connection of KEYENCE PC application software, in addition to the function described above, uploading and downloading the inspection
settings, simulations, data, including image data can be sent or received.
• VisionDatabase function support (sold separately)
• For the FTP client function, the VNC server function (for clients other than for PC it will be only for the screen display), and BOOTP function.
• 1000BASE-T/100BASE-TX/10BASE-T
USB
• By the connection of KEYENCE PC application software, in addition to numerical value output and control input/output , uploading and
downloading the inspection settings, simulations, data, including image data can be sent or received
• VisionDatabase function support (sold separately)
• USB2.0
CC-Link
• By connecting the optional CC-Link expansion unit CA-NCL10E, numerical value input/output and control input/output are enabled. (Do not use to
connect to PLC Link, EtherNet/IP and PROFINET.)
• Compatible to the Ver.1.10 remote device station, Ver.2.00 remote device station
EtherNet/IP
Numerical value input/output, and control input/output by using the Ethernet port enabled. (Do not use to connect to PLC Link, CC-Link and
PROFINET.)
• Compatible to the cyclic communication (max.1436 byte), and message communication
• Maximum number of connections 32
• Compatible with the conformance test Version.CT10
PROFINET
Numerical value input, and control input/output by using the Ethernet port enabled.
• Compatible to the cyclic communication (max. 1408 byte)
• Compatible to the aperiodic (recorded data) communication
• Compatible with the Conformance Class A
• Do not use to connect to PLC Link, CC-Link and EtherNet/IP.
Console
• By the optional OP-84231, OP-84236 (without silk screen printing), various menu can be used
• Compatible to the operation assignment settings to the console button
• Compatible to the button activation and deactivation of each user group
Touch Panel
• Setting operation from the CA Series touch panel used by the RS-232 port is possible
• For the dedicated touch menu or the operation button
Display language
Japanese/English/Simplified Chinese/Traditional Chinese/German selectable
(Choose the default language to be used when turning power ON)
Illumination control
Based on connecting the Illumination Expansion Unit
The optional the lighting and light intensity control CA-DC21E of the LED illumination (12 V, 24 V) is possible, 2ch per unit, and a maximum number
of connected units of 4.
Rating
Power source voltage 24 VDC ±10%
Consumption current
3.8 A (2 Cameras)/4.9 A (4 Cameras)/5.9 A (6 Cameras)/
6.9 A (8 Cameras)
When either one is turned ON, at the time of maximum load including
the input current. • Line Scan Camera: 3.1 A (1 Camera)/3.4 A (2 Cameras)/
3.6 A (3 Cameras)/3.9 A (4 Cameras)
• Area Scan Camera: 3.8 A (2 Cameras)/4.9 A (4 Cameras)/
5.9 A (6 Cameras)/6.9 A (8 Cameras)
When either one is turned ON, at the time of maximum load including
the input current.
Environmental
resistance Ambient temperature 0 to +45°C
Ambient operating humidity 35 to 85% RH (no condensation)
Weight Approx. 2000 g
