10

XG-8500L(P)/8502L(P)/8700L(P)/8702L(P)

*1 For the type where a P is added to the end of the main unit, it will become a PNP Open Collector.

*2 Models equipped with the Ethernet port in the CPU unit support Ethernet port direct connection.

*3 A 21 mega-pixel Area Scan Camera and a Line Scan Camera cannot be connected at the same time.

Model type

XG-8700L/8702L

XG-8500L/8502L

Pixels

• With CA-H2100C/H2100M, XG-H2100C/H2100M connected

21 mega-pixel mode: 5104(H)x4092(V), approx. 20.89 mega-pixels

5 mega-pixel mode: 2432(H)x2050(V), approx. 4.99 mega-pixel

• With XG-HL08M is connected:

8192(H) x 8192(L), approx. 67.11 mega-pixels

• With XG-HL04M is connected:

4096(H) x 16384(L), approx. 67.11 mega-pixels

• With XG-HL02M is connected:

2048(H) x 16384)L), approx. 33.55 mega-pixels

• With CA-HX500C/HX500M connected

5 mega-pixel mode: 2432(H) x 2040(V), approx. 4.96 mega-pixels

2 mega-pixel mode: 1600(H) x 1200(V), approx. 1.92 mega-pixels

• With CA-HX200C/HX200M connected

2 mega-pixel mode: 1600(H) x 1200(V), approx. 1.92 mega-pixel

• With CA-HX048C/HX048M connected

470 k pixel mode: 784(H) x 596(V), approx. 470,000 pixels

310 k pixel mode: 640(H) x 480(V), approx. 310,000 pixels

240 k pixel mode: 512(H) x 480(V), approx. 240,000 pixels

• With XG-H500C/H500M connected 5 mega-pixel mode: 2432(H) x

2050(V), approx. 4.99 mega-pixels

• With XG-200C/S200C/H200C/200M/S200M/H200M connected

2 mega-pixel mode: 1600(H) x 1200(V), approx. 1.92 mega-pixels

1 mega-pixel mode: 1024(H) x 960(V), approx. 980,000 pixels

• With XG-H100C/H100M connected 1000(H) x 1000(V), 1 mega-pixel

• With XG-035C/S035C/H035C/035M/S035M/H035M connected

310 k pixel mode: 640(H) x 480(V), approx. 310,000 pixels

240 k pixel mode: 512(H) x 480(V), approx. 240,000 pixels

• With XG-HL02M is connected: 2048(H) x 16384(L), approx. 33.55

mega-pixels

• With CA-HX200C/HX200M connected

2 mega-pixel mode: 1600(H) x 1200(V), approx. 1.92 mega-pixel

• With CA-HX048C/HX048M connected

470 k pixel mode: 784(H) x 596(V), approx. 470,000 pixels

310 k pixel mode: 640(H) x 480(V), approx. 310,000 pixels

240 k pixel mode: 512(H) x 480(V), approx. 240,000 pixels

• With XG-200C/S200C/H200C/200M/S200M/H200M connected

2 mega-pixel mode: 1600(H) x 1200(V), approx. 1.92 mega-pixels

1 mega-pixel mode: 1024(H) x 960(V), approx. 980,000 pixels

• With XG-H100C/H100M connected 1000(H) x 1000(V),

1 mega-pixel

• With XG-035C/S035C/H035C/035M/S035M/H035M connected

310 k pixel mode: 640(H) x 480(V), approx. 310,000 pixels

240 k pixel mode: 512(H) x 480(V), approx. 240,000 pixels

Camera input

• When the CA-EC80/XG-EC80 is equipped: 2 color/monochrome

cameras (Compatible with CA-HX500C/HX500M/HX200C/HX200M/

HX048C/HX048M and XG-H500C/200C/S200C/ H200C/H100C/

035C/ S035C/H035C/H500M/200M/S200M/H200M/ H100M/035M/

S035M/H035M)

• When the CA-EC80L (Standard equipment)/XG-EC80L is equipped: 1

monochrome Line Scan Camera (Compatible with XG-HL02M/

HL04M/HL08M) or 1 color/monochrome Area Scan Camera

(Compatible with CA-H2100C/H2100M, XGH2100C/H2100M and

CAHX500C/HX500M/HX200C/HX200M/HX048C/HX048M)

• When the CA-EC80HX is equipped: 1 color/monochrome Area Scan

Camera (Compatible with CA-HX500C/HX500M/HX200C/HX200M/

HX048C/HX048M)

• When the CA-EC80/XG-EC80 is equipped: 2 color/monochrome

cameras (Compatible with CA-HX200C/HX200M/HX048C/HX048M

and XG-200C/S200C/ H200C/H100C/035C/ S035C/H035C/ 200M/

S200M/H200M/ H100M/035M/S035M/H035M, mixed connection is

possible

• When the CA-EC80L (Standard equipment)/XG-EC80L is equipped: 1

monochrome Line Scan Camera (Compatible with XG-HL02M) or 1

color/monochrome Area Scan Camera (Compatible with CA-HX200C/

HX200M/HX048C/HX048M)

• When the CA-EC80HX is equipped: 1 color/monochrome Area Scan

Camera (Compatible with CA-HX200C/HX200M/HX048C/HX048M/)

If the expansion unit CA-E800/XG-E800 is connected, when the

CA-EC80L/XG-EC80L is equipped, 1 extra line scan camera or 1 extra

21 mega-pixel camera (2 cameras maximum) can be connected; when

the CA-EC80HX/CA-EC80L/XG-EC80L is equipped, 1 extra area scan

camera (only the CA-HX500C/HX500M/HX200C/HX200M/HX048C/

HX048M; 2 cameras maximum) can be connected; and when the

CA-EC80/XG-EC80 is equipped, 2 extra area scan cameras (4 cameras

maximum) can be connected (mixed connection is possible).

If the expansion unit CA-E800/XG-E800 is connected, when the

CA-EC80L/XG-EC80L is equipped, 1 extra line scan camera (2 cameras

maximum) can be connected; when the CA-EC80HX/CA-EC80L/

XG-EC80L is equipped, 1 extra area scan camera (only the

CA-HX200C/HX200M/HX048C/HX048M; 2 cameras maximum) can be

connected; and when the CA-EC80/XG-EC80 is equipped, 2 extra area

scan cameras (4 cameras maximum) can be connected (mixed
connection is possible)

*3

.

Trigger input

Simultaneous capture by up to 4 cameras/individual capture can be selected. (when CA-E800/XG-E800 is not connected, up to 2 cameras can be

connected simultaneously)

Main image processor

DSP (High-speed)

Registered number of inspection settings

SD cards 1 and 2 can each hold 1000 programs (depending on the size of the SD card and the size of the programs), external switching possible

Number of registered screens

Maximum 1000 screens for each program (depending on SD card size), Image compression.

SD card

• SD card slot x 2 (SDHC compatible)

• Compatible with OP-87133 (512MB), CA-SD1G (1GB: installed

standard to SD1), and CA-SD4G (4GB: SDHC)

• SD card slot x 2 (SDHC compatible)

• Compatible with OP-87133 (512MB: installed standard to SD1),

CA-SD1G (1GB), and CA-SD4G (4GB: SDHC)

Interface

Controlled input (compatible with

arbitrary assignment)

• 20 input (including four high speed inputs designed for trigger input)

• Input rating 26.4 V or lower, 2 mA or greater (3 mA or greater for high speed input terminal)

Controlled output (compatible with

arbitrary assignment)

• 32 output (including four high speed outputs designed for FLASH outputting linked to external device)
• NPN open collector

*1

Maximum 50 mA (30 V or less)

Encoder input

For the Open Collector Output (Dedicated to 24-V outputs) using the RS-422 Line Driver Output Terminal (with 5 V output: Maximum 150 mA) and

Control Input Terminal. (Choose each system or for the open collector output, choose two systems.)

Monitor output

Analog RGB Output, XGA (1024 x 768, 24 bit color)/SVGA (800 x 60, 24 bit color) Switch (can be set by the inspection settings unit)

Operation indicators

LED display for Power ON, Operation and ERROR

RS-232C

2 Port up to Maximum baud rate of 230400 bps

The digit output or control input/output and CA Series Touch Panel interface can be switched.

PLC link

• Numerical value output and control input/output using the RS-232C port or Ethernet port enabled (Do not use to connect to CC-Link, EtherNet/IP

and PROFINET.)

• Following PLCs are supported via link unit:

*2

KEYENCE: KV-700 Series, KV-1000 Series, KV-3000 Series, KV-5000 Series, KV-5500 Series, KV Nano Series

Mitsubishi Electric: MELSEC A Series (RS-232C only), Q Series, L Series

OMRON: SYSMAC C Series (RS-232C only), CP1/CS1/CJ1/CJ2 Series

YASKAWA Electric: MP900 Series (RS-232C only), MP2000 Series

Ethernet

• Numerical value output, and control input/output enabled.

• By the connection of KEYENCE PC application software, in addition to the function described above, uploading and downloading the inspection

settings, simulations, data, including image data can be sent or received.

• VisionDatabase function support (sold separately)

• For the FTP client function, the VNC server function (for clients other than for PC it will be only for the screen display), and BOOTP function.

• 1000BASE-T/100BASE-TX/10BASE-T

USB

• By the connection of KEYENCE PC application software, in addition to numerical value output and control input/output , uploading and

downloading the inspection settings, simulations, data, including image data can be sent or received.

• VisionDatabase function support (sold separately)

• USB2.0

CC-Link

• By connecting the optional CC-Link expansion unit CA-NCL10E, numerical value input/output and control input/output are enabled. (Do not use to

connect to PLC Link, EtherNet/IP and PROFINET.)

• Compatible to the Ver.1.10 remote device station, Ver.2.00 remote device station

EtherNet/IP

Numerical value input/output, and control input/output by using the Ethernet port enabled. (Do not use to connect to PLC Link, CC-Link and PROFINET.)

• Compatible to the cyclic communication (max.1436 byte), and message communication

• Maximum number of connections 32

• Compatible with the conformance test Version.CT10

PROFINET

Numerical value input, and control input/output by using the Ethernet port enabled.

• Compatible to the cyclic communication (max. 1408 byte)

• Compatible to the aperiodic (recorded data) communication

• Compatible with the Conformance Class A

• Do not use to connect to PLC Link, CC-Link and EtherNet/IP.

Console

• By the optional OP-84231, OP-84236 (without silk screen printing), various menu can be used

• Compatible to the operation assignment settings to the console button

• Compatible to the button activation and deactivation of each user group

Touch Panel

• Setting operation from the CA Series touch panel used by the RS-232 port is possible

• For the dedicated touch menu or the operation button

Display language

Japanese/English/Simplified Chinese/Traditional Chinese/German selectable

(Choose the default language to be used when turning power ON)

Illumination control

By connecting the optional illumination expansion unit CA-DC30E/DC21E, the lighting and light intensity of the LED illumination (12 V, 24 V) can be

controlled, there are two channels per unit, and a maximum of four units can be connected. By connecting the illumination expansion unit

CA-DC30E, the lighting and light intensity of the LED illumination (12 V, 24 V) can be controlled, there are two channels per unit, and a maximum of

two units can be connected.

Rating

Power source voltage

24 VDC ±10%

Consumption current

• Line Scan Camera: 3.2A (1 camera)/ 3.7A (2 Cameras)

• Area Scan Camera: 3.6A (2 Cameras)/ 4.7A (4 Cameras),

when either one is turned ON, at the time of maximum load including the

input current.

• Line Scan Camera: 3.0A (1 camera)/ 3.3A (2 Cameras)

• Area Scan Camera:3.6A (2 Cameras)/ 4.7A (4 Cameras),

when either one is turned ON, at the time of maximum load including the

input current.

Environmental

resistance

Ambient temperature

0 to +45°C

Ambient operating humidity

35 to 85% RH (no condensation)

Weight

Approx. 1600 g
