21
SPECIFICATIONS
1. Linearity was obtained using KEYENCE’s standard target (zirconia block gauge) with the sampling cycle set to 2048 µs.
2. Repeatability was obtained using KEYENCE’s analog sensor controller RD-50 with the sampling cycle set to 2048 µs and the number of measurements to be averaged set to 64.
Note: The ripple of the analog output may be 1 mV or more due to common mode noise when observed with an oscilloscope or high-speed A/D conversion board.
3. When measurement is impossible, 12 V (21 mA) is output.
Model Sensor head LK-011
Controller LK-3101
Measurement mode Normal Mirror-surface measurement
Reference distance 10 mm 7.2 mm
Measuring range ±1 mm ±0.9 mm
Light source Red semiconductor laser
Wavelength 670 nm (visible beam)
Output 0.95mW
Spot diameter Approx. 20 µm (at the reference distance)
Linearity 1. ±0.25% of F.S. ±0.25% of F.S.
Repeatability 2. 0.1 µm
Analog output 3. Voltage output ±10 V (0.1 µm/mV) ±9 V (0.1 µm/mV)
Output impedance 100 Ω
Current output 4 to 20 mA (350 Ω max.)
Alarm output NPN open-collector (N.C.), 100 mA max. (40 V max.), Residual voltage 1 V max.
Sampling cycle 128/256/512/2048 µs selectable
Other functions AUTO ZERO, Analog output hold during alarm, GAIN selection, Response speed selection,
Mirror-surface measurement mode, Span/Shift adjustment, Sampling cycle selection
Power supply 24 VDC ±10%, Ripple (p-p): 10% max.
Current consumption 400 mA max.
Temperature fluctuation Sensor head 0.04% of F.S. / °C (+20 to +30°C (68 to 86°F))
Controller 0.05% of F.S. / °C (0 to +50°C (32 to 122°F))
Enclosure rating IP64
Ambient light Incandescent or fluorescent lamp: 10,000 lux max.
Ambient temperature 0 to +50 °C (32 to 122°F), No condensation
Relative humidity 35 to 85%, No condensation
Material Sensor head Aluminum die-cast
Controller Polycarbonate
Weight Sensor head Approx. 80 g
Controller Approx. 515 g
