■ Additional function setting mode
You can set the following functions in the additional function setting mode.
● How to enter the added function setting mode
Enter the added function setting mode by the following procedure.
• In the main display, press the [MODE] button and the left Arrow
button at the same time for at least two seconds.
Reference
The items that can be selected (displayed) are different
depending on the settings in "A1. Calculation mode".
(When the expansion unit is not added, the items that can be
selected (displayed) are the same as for "noCALc".
*1 This can be set only on the main unit that an expansion
unit is added.
*2 On the expansion unit, this can be set only when "C5.rEF
(Reference difference) is selected in "A2. Calculation Mode".
*3 This can be set only when "C5.rEF (Reference
difference)" is selected in "A2. Calculation method".
Special output setting
Not used
5-output
Limit output
Limit output user setting
All GO
All limit output
*
1
*
1
O O O O O -
O O*
2 O O O*
3 -
O O - - O O
A1.
Calculation mode
16. Special output
setting
Reference
position set
Limit output HH side teaching
Only available when "Lt.USEr" is selected in [ Special output setting].
Setting value
input screen
Limit output HH side criterion position setting
Only available when "Lt.USEr" is selected in [ Special output setting].
Reference
position set
Limit output LL side teaching
Only available when "Lt.USEr" is selected in [ Special output setting].
Setting value
input screen
Limit output LL side criterion position setting
Only available when "Lt.USEr" is selected in [ Special output setting].
Default
Free range settings
Analog range setting
Free range settings (Hi)
Only available when "FrEE" is selected in " Analog range setting".
Setting value
input screen
No. Item Description
Select preset data Select the data to use when performing the preset.
Store preset value Set whether or not to save "zero-point correction".
Preset point
Set the memory method for "zero-point
correction" when using the bank function.
Power-save
function (ECO) To decrease the power consumption or not to
display the numerical value, set this function.
Jam detection function When the spindle does not fully extend.
- Jam detection teaching Set the reference position for the jam detection.
Jam detection
check point setting Set the position to perform the jam detection
function with the reference position being 0.
Setting value
input screen
Free range settings (Lo)
Only available when "FrEE" is selected in " Analog range setting".
GT2-71 GT2-71 Left Arrow button
[MODE] button
Main screen
R.V. value
Select preset data
P.V. value
Not available to set on the main unit for which "CAL.noH" is selected in [ Calculation mode].
YES
Store preset value
NO
Not available to set on the main unit for which "CAL.noH" is selected in [ Calculation mode].
Common for
all banks
Preset point setting
Save for
each bank
Not available to set on the main unit for which "CAL.noH" is selected in [ Calculation mode].
OFF
Power-save function
ECO Half
ECO All
