Transmission Type Laser Detection Sensor
IB Series Setting Guide
Amplifier Display
 Names of the part of the amplifier
(1) Main display
(2) Laser emission LED
(3) Judgment LED
(4) Analog range LED
(5) Program bank LED
(6) ZERO SHIFT button
(7) Sub display explanation LED
(8) Sub display
(9) Timing input LED
(10) Zero Shift input LED
(11) SET button
(12) MODE button
(13) Arrow buttons
(14) Alarm LED
(15) Calculation LED
(16) Hold input LED
 Digital LED Display
● Main Display
Normal
The internal measurement value is
displayed.
When Hold function is used
The held value is displayed.
● Sub display
The Sub display can be switched by pressing the left/right arrow
buttons.
R.V.(Internal measurement value)
The actual measurement value is
displayed. This is not held.
Analog output (when it is set ON)
The voltage value (V) or the current (mA)
value is displayed.
HIGH Limit setting value
The upper limit set is displayed.
LOW limit setting value
The lower limit set is displayed.
Shift target value
When the ZERO SHIFT button is pressed,
the R.V. will be matched to the value set
here.
LASER
BANK 0 1 2 3
HI
LO
R.V. ANALOG
HI S HIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
HOLD C ALC CHECK
GO
GO
HOLD C ALC CHECK
LASER
BANK 0 1 2 3
HI
LO
R.V. ANALOG
HI S HIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
GO
LASER
BANK 0 1 2 3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
HOLD C ALC CHECK
GO
HOLD C ALC CHECK
LASER
BANK 0 1 2 3
HI
LO
R.V. ANALOG
HI S HIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
GO
HOLD C ALC CHECK
LASER
BANK 0 1 2 3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
459GB
(1)
(2)
(3)
(4)
(5)
(6) (7) (8) (9) (10) (11) (12)
(16) (15) (14)
(13)
[HOLD] ON
R.V.
[R.V.]
ON
Analog output
[ANALOG]
ON
HIGH setting value
[HI]
ON
LOW setting value
[LO]
ON
Shift target value
[SHIFT]
ON
