Specifications

*1 Use a cable length of 30 m or less for M8 connector and e-CON connector types.
*2 Counted as 1 output when connecting with the network unit NU Series.
*3 FS-N11MN only
*4 SUPER : 1.2 ms, ULTRA : 1.8ms, MEGA : 4.2 ms
*5 Input time is 25 ms (ON)/25 ms (OFF) only when external calibration input is selected.
*6 Increases 100 mW (4.0 mA) for High Speed mode
*7 One or two more units connected: -20 to +55 °

C; 3 to 10 more units connected: -20 to +50 °

C; 11 to 16 more units connected: -20 to +45°

C. When using 2-outputs, one unit is counted as two units.

All temperature regulations are for when the unit is mounted on a DIN rail and installed on metal sheeting.

WARRANTIES AND DISCLAIMERS

(1) KEYENCE warrants the Products to be free of defects in materials and workmanship for a

period of one (1) year from the date of shipment. If any models or samples were shown to
Buyer, such models or samples were used merely to illustrate the general type and quality
of the Products and not to represent that the Products would necessarily conform to said
models or samples. Any Products found to be defective must be shipped to KEYENCE with
all shipping costs paid by Buyer or offered to KEYENCE for inspection and examination.
Upon examination by KEYENCE, KEYENCE, at its sole option, will refund the purchase
price of, or repair or replace at no charge any Products found to be defective. This warranty
does not apply to any defects resulting from any action of Buyer, including but not limited to
improper installation, improper interfacing, improper repair, unauthorized modification,
misapplication and mishandling, such as exposure to excessive current, heat, coldness,
moisture, vibration or outdoors air. Components which wear are not warranted.

(2) KEYENCE is pleased to offer suggestions on the use of its various Products. They are only

suggestions, and it is Buyer's responsibility to ascertain the fitness of the Products for
Buyer’s intended use. KEYENCE will not be responsible for any damages that may result
from the use of the Products.

(3) The Products and any samples ("Products/Samples") supplied to Buyer are not to be used

internally in humans, for human transportation, as safety devices or fail-safe systems,
unless their written specifications state otherwise. Should any Products/Samples be used in
such a manner or misused in any way, KEYENCE assumes no responsibility, and
additionally Buyer will indemnify KEYENCE and hold KEYENCE harmless from any liability
or damage whatsoever arising out of any misuse of the Products/Samples.

(4) OTHER THAN AS STATED HEREIN, THE PRODUCTS/SAMPLES ARE PROVIDED

WITH NO OTHER WARRANTIES WHATSOEVER. ALL EXPRESS, IMPLIED, AND
STATUTORY WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-
INFRINGEMENT OF PROPRIETARY RIGHTS, ARE EXPRESSLY DISCLAIMED.
IN NO EVENT SHALL KEYENCE AND ITS A FFILIATED ENTITIES BE LIABLE TO ANY
PERSON OR ENTITY FOR ANY DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, SPECIAL
OR CONSEQUENTIAL DAMAGES (INCLUDING, WITHOUT LIMITATION, ANY
DAMAGES RESULTING FROM LOSS OF USE, BUSINESS INTERRUPTION, LOSS OF
INFORMATION, LOSS OR INACCURACY OF DATA, LOSS OF PROFITS, LOSS OF
SAVINGS, THE COST OF PROCUREMENT OF SUBSTITUTED GOODS, SERVICES OR
TECHNOLOGIES, OR FOR ANY MATTER ARISING OUT OF OR IN CONNECTION
WITH THE USE OR INABILITY TO USE THE PRODUCTS, EVEN IF KEYENCE OR ONE
OF ITS AFFILIATED ENTITIES WAS ADVISED OF A POSSIBLE THIRD PARTY’S
CLAIM FOR DAMAGES OR ANY OTHER CLAIM AGAINST BUYER. In some
jurisdictions, some of the foregoing warranty disclaimers or damage limitations may
not apply.

BUYER'S TRANSFER OBLIGATIONS:

If the Products/Samples purchased by Buyer are to be resold or delivered to a third party,
Buyer must provide such third party with a copy of this document, all specifications,
manuals, catalogs, leaflets and written information provided to Buyer pertaining to the
Products/Samples.

E 1110-2

Type

Standard 1 output

High functionality 2 output

Monitor output

0-line

Cable/M8 connector

Cable

M8 connector

e-CON connector

Cable

M8 connector

Cable

Main unit/expansion unit

Main unit

Expansion unit

(with output cable)

Main unit

Expansion unit

(with output cable)

Main unit

Expansion unit

(with output cable)

Main unit

Expansion unit

(with output cable)

Main unit

Expansion unit

(with output cable)

Main unit

Expansion unit

(without output cable)

Model

NPN

FS-N11N

FS-N12N

FS-N11CN

FS-N12CN

FS-N11EN

FS-N12EN

FS-N13N

FS-N14N

FS-N11MN

FS-N10

PNP

FS-N11P

FS-N12P

FS-N11CP

FS-N12CP

FS-N13P

FS-N14P

FS-N13CP

FS-N14CP

Control output

1 output

2 output

1 output

N/A

Monitor output (1 to 5 V)

1 output

External input

1 input

Light source LED

Red 4-element LED (wavelength 630 nm)

Response time

50 μs (HIGH SPEED)/250 μs (FINE)/500 μs (TURBO)/1 ms (SUPER)/4 ms (ULTRA)/16 ms (MEGA)

Output toggle

Light-ON/dark-ON toggle

Timer function

Timer OFF, OFF delay, ON delay, One-shot

Control
output

NPN output

NPN open collector 24 V; 1 output max: 100 mA or less; 2 output total:

100 mA or less (used stand-alone)/20 mA or less (multiple connections); residual voltage 1 V or less

PNP output

PNP open collector 24 V; 1 output max: 100 mA or less; 2 output total:

100 mA or less (used stand-alone)/20 mA or less (multiple connections); residual voltage 1 V or less

Monitor output

1 to 5 V voltage output; load resistance 10 k

Ω or more; repeat precision ± 0.5% of F.S.; 1 ms response time (HIGH SPEED, FINE, TURBO)

External input

input time 2 ms (ON)/20 ms (OFF) or more

Expansion Units

Up to 16 units can be connected (total of 17 units including the main unit). Note that the two-output type is counted as two units.

Protection circuit

Protection against reverse power connection, output overcurrent, and output surge

Number of interference
prevention units

0 for HIGH SPEED; 4 for FINE; 8 for TURBO/SUPER/ULTRA/MEGA (When set to double, the number of interference-prevention units will be doubled.)

Rating

Power voltage

12 to 24 V DC ± 10% ripple (P-P) 10% or less

NPN

Normal:900 mW or less (36 mA max. at 24 V, 48 mA max. at 12 V)

Eco on mode:800 mW or less (32 mA max. at 24 V, 39 mA max. at 12 V)

Eco Full mode:470 mW or less (19 mA max. at 24 V, 23 mA max. at 12 V)

PNP

Normal

: 950 mW or less (39 mA max. at 24 V, 52 mA max. at 12 V)

Eco on mode

: 850 mW or less (35 mA max. at 24 V, 44 mA max. at 12 V)

Eco Full mode

: 520 mW or less (21 mA max. at 24 V, 26 mA max. at 12 V)

Normal

: 1050 mW or less (42 mA max. at 24 V,

56 mA max. at 12 V)

Eco on mode

: 950 mW or less (38 mA max. at 24 V,

47 mA max. at 12 V)

Eco Full mode : 600 mW or less (24 mA max. at 24 V,

29 mA max. at 12 V)

Environme
ntal
resistance

Operating ambient
luminance

Incandescent lamp: 20,000 lx or less; Sunlight: 30,000 lx or less

Operating ambient
temperature

-20 to +55 °

C (no freezing)

Operating ambient
humidity

35 to 85% RH (no condensation)

Vibration
resistance

10 to 55 Hz Compound amplitude 1.5 mm, 2 hours for each of X,Y,Z axis

Shock resistance

500 m/s

3 times for each of X,Y,Z axis

Case material

Both main unit and expansion unit housing material: Polycarbonate

Case dimensions

H30.3mm x W9.8mm x L71.8mm

Weight

Approx 75g

Approx 45g

Approx 22g

Approx 80g

Approx 70g

Approx 22g

Approx 75g

Approx 20g
