PT300 Users manual
Rev G, Feb 2011
Page 42 of 44
Step Entries
The ‘step’ choice that starts the calibration menu also allows special codes for technical diagnostic
work. Typically only scale technicians should use these features. Here is the list of possible
entries to the ‘step’ choice related to the PT300:
Message Meaning
000 000 000 000
Simply advance to the first Calibration Menu step.
001 001 001 001
Advance to weight calibration.
003 003 003 003
Enter corner calibration. (Also set the number of load cell inputs here.)
005 005 005 005
This brings you to the Mode Menu, just as if the cal strap had been left
in the RUN position.
121 121 121 121
Raw counts display diagnostic
131 131 131 131
Constant power to all cells diagnostic
201-208 201-208 201-208 201-208
Corner adjust cell 1-8. (Example: 202 will enter mode to adjust cell #2).
311 311 311 311
Restore all radio settings to defaults (CH = 1, Network ID = 8000, and
Encryption disabled). Display will then show ‘save’ if successful, or
“no rf
no rf no rf no rf” if there is no radio installed or some other radio failure.
711 711 711 711
Restore all settings to defaults, but leave weight calibration untouched.
911 911 911 911
Restore all settings to default settings, including weight calibration. It is
recommended that this only be used as a last resort, as your previous
calibration and settings will be lost after running this.
Step Choice Table
