PT300 Users manual
Rev G, Feb 2011
Page 32 of 44
Setting the Calibration Parameters
1. At any point in the following steps, data will be retained by the scale at the step completed if
the power is cycled off. To initiate calibration simultaneously press the PRINT/ACCUMULATE
and the ZERO buttons. The scale shows “StEP
StEP StEP StEP”. Press the PRINT/ACCUMULATE button.
The scale shows “000 000 000 000” with the far right number flashing. To go through all of the calibration
parameters, press PRINT/ ACCUMULATE with the display showing “000 000 000 000”. To skip the first 8
calibration parameters and proceed to step 11 enter “001 001 001 001”. See Diagnostics section for
additional codes available. Use the LOCAL/TOTAL button to increment and the ZERO button
to decrement the number. Press the PRINT/ ACCUMULATE button when the desired number
is displayed.
3. The display shows “U UU U. EnA EnA EnA EnA” if proceeding through all parameters. Press the PRINT/
ACCUMULATE button. The display will read “YES YES YES YES”. Pressing LOCAL/TOTAL or the ZERO
button will toggle the display to “no no no no”. With the display showing “YES YES YES YES”, press the
PRINT/ACCUMULATE button.
4. The display now shows “bP 1 bP 1 bP 1 bP 1”. Press the PRINT/ACCUMULATE button. The display will read
the current setting with the far right number flashing. Use the LOCAL/TOTAL button to
advance the number and the ZERO button to move the number flashing to the left. When the
desired graduation break point is displayed press the PRINT/ ACCUMULATE button.
5. The display shows “bP 2 bP 2 bP 2 bP 2”. Press the PRINT/ACCUMULATE button. Repeat the process in
step 3 for graduation break point 2. When the desired graduation break point is displayed
press the PRINT/ACCUMULATE button.
6. The display shows “bP 3 bP 3 bP 3 bP 3”. Press the PRINT/ACCUMULATE button. Repeat the process in
step 3 for graduation break point 3. When the desired graduation break point is displayed
press the PRINT/ACCUMULATE button.
Multiple Graduation Break Points
The PT300 has the ability to have multiple graduation values set. Following is an example
of setting graduation break points. Example:
Grad = Initial graduation equals by 0.1 lb
Cap = 10000 (Capacity equals 10,000 lb)
bP 1
bP 1 bP 1 bP 1 = 1000
bP 2
bP 2 bP 2 bP 2 = 2000
bP 3
bP 3 bP 3 bP 3 = 5000
