Chapter 5 - Operating Procedures
5-1
CHAPTER 5 - OPERATING PROCEDURES
A Brief Description of
Chapter 5 All information contained in Chapter 5 pertains to the
operation of the HI WS100 Configuration Software.
The Operating Procedures include, Reading Live
Weight, Calibration, Creating or modifying Set-
point(s) Parameters, reading C2 load cell serial num-
bers and quickly monitoring Gross Weight (remote
modules only) for the HI 1746-WS Weigh Module.
NOTE: The HI WS100 will not read non-C2 load cell serial
numbers.
Reading Live Weight, Step 1. Click on the Live Weight Tab. The Live
Weight page appears. (See Fig. 5-1) The
Gross, Net and Tare weights are displayed.
In addition the Rate of Change (ROC) and
the ROC Units are displayed. Relay 1 and
Relay 2 status are displayed.
FIG. 5-1 LIVE WEIGHT PAGE
Taring the HI 1746-
WS Step 2. To Tare the HI 1746-WS click on the Tare
button.
