Chapter 4 - Setup
4-1
CHAPTER 4 - SETUP
A Brief Description of
Chapter 4 All information contained in Chapter 4 pertains to
firmware and software settings to prepare the HI
1746WS Weight Module controller for calibration
and operation. Alternatives to these procedures
explicit or implied, contained in this section are not
recommended. It is very important that the user and
service personnel be familiar with the procedures con-
tained in this chapter, before going through the setup
procedures. The Setup procedures require either
Allen-Bradley DOS PLC 500 AI Series Ladder Logic
Editor*, or Allen-Bradley RSLogix 500* and Allen-
Bradley RSLinx™ or RSLinx™ Lite.
Presetup Procedures Step 1. Make sure that the HI 1746-WS is
installed in the rack correctly.
Step 2. Make sure that the HI 1746-WS has been
setup correctly and that all data necessary
to run the HI 1746-WS module has been
entered into RSLogix 500 configuration
software.
Step 3. Check the module ID code to verify that
the jumper has been set for the proper
mode of operation (Local ID Code =
13635, Remote ID Code = 3235). If you
have put the HI 1746-WS module in a
local rack and get the 3235 ID number the
jumper is set incorrectly.
Step 4. If you have set the jumper for the HI 1746-
WS module for local mode of operation
and placed the module in a remote rack the
1747 ASB will display an invalid module
error.
Step 5. If these errors occur, remove the HI 1746-
WS and reset the jumper to the proper
mode of operation. (See the HI 1746-WS
Weigh Module Installation and Operation
Manual (Prt. #0596-0234-01), Chapter 3,
Page 3-2 for instructions)
Step 6. Reinstall the module.
Step 7. Repeat Steps 3 & 4.
