Model 5i Digital Force / Torque Indicator User’s Guide
28
Note: If the AC adapter is plugged in, the indicator will ignore these settings and keep the backlight on,
unless the BACKLIGHT key is pressed. Selecting the On or Off setting in the Backlight menu will
manually turn the backlight on or off as if the Backlight button were pressed.
12.3 LCD Contrast
The contrast of the display may be adjusted. Select LCD Contrast from the menu. The screen will appear
as follows:
Press ENTER to modify the contrast. Select a value from 0 to 25, 25 producing the most contrast.
12.4 Beeps
Audible tones can be enabled for all key presses and alerts, such as overload, set point value reached,
etc. The Set Point alert can be configured to be either a momentary tone or a continuous tone (until the
load is restored to a value between the set points). To configure the functions for which audible tones will
apply, select Beeps from the menu. The screen will appear as follows:
12.5 Initial settings
This section is used to configure the initial settings upon powering on the indicator. The initial units of
measurement and the primary reading measurement mode may be configured. To access these settings,
select Initial Settings from the menu. The screen will appear as follows:
The default unit of measure depends on the sensor series. The default mode is Real Time, regardless of
sensor.
INITIAL SETTINGS
Units
LBF
Mode
Real Time
BEEPS
Keys
* Alerts
Set Points
* Momentary
Continuous
LCD CONTRAST
Set Contrast
10
