Model 5i Digital Force / Torque Indicator
User’s Guide
26
11.1 Calibration Password
Select Calibration from the sub-menu. The display will appear as follows:
To set the password, select Enabled , then Set Password. Use the UP and DOWN keys to increment
and decrement the value, from 0 to 9999. When the desired value has been selected, press ENTER, then
ESC to exit the sub-menu.
11.2 Menu Key Password
If enabled, every time the MENU key is selected, a password must be provided. Select Menu Key from
the sub-menu. Follow the same procedure as described in section 10.1.
11.3 Locking Out Other Keys
Other keys may be locked out individually. Select any combination of keys (UNITS, MODE, ZERO,
DATA) by pressing ENTER in the Passwords sub-menu. Pressing a locked key will prompt the message
“KEY PROTECTED” and then revert to the previous screen.
11.4 Password Prompts
If passwords have been enabled, the following will be displayed when pressing the MENU key or
accessing the Calibration section:
Use the UP and DOWN keys to select the correct password, then press ENTER to continue.
If the incorrect password has been entered, the display will appear as follows:
ENTER PASSWORD
(0000 – 9999)
5000
INCORRECT PASSWORD
Reset password
Request code:
XXXX
Press ENTER or ESC
CALIBRATION PASSWORD
*
Disabled
Enabled
Set Password
(0000 – 9999)
5000
