- 13 -
II.8 Printing
The DV-II + will print data to an attached Serial printer. The printer must be attached to the rear panel
SERIAL AND ANALOG output connector. See Appendix G for the connection requirements.
The printer must be configured as follows:
Baud Rate 9600
Data Bits 8
Stop Bits 1
Parity None
Handshake None
Data may be printed in two ways:
1. Pressing the PRINT key once (for less than three (3) seconds) will result in the printing of one
standard print line.
2. If the PRINT key is pressed and held for more than three (3) seconds, the user will be presented
with the following screen:
Figure 20
Here the user is being asked to enter the time interval (in minutes and seconds) between
successive print strings. First, as depicted above the user is asked for the minutes entry and then
by pressing the print key the seconds entry as shown below:
Figure 21
The print interval maximum limits are 99 minutes and 59 seconds.
3. The method for entering the minutes and seconds values is accomplished by using the UP or
DOWN arrow keys. The PRINT key is used to advance from the minutes to seconds entries and
as the exit key after the user has input the seconds value.
Note: The value for minutes or seconds must be other than zero or you will not be able to exit
this mode.
-100
°
C to +150
°
C
±
1.0
°
C
+150
°
C to +300
°
C
±
2.0
°
C
TABLE 2
Temperature Accuracies For
Digital Viscometer Model DV-II+
Temperature Range Temperature Accuracy
