38 n
etwork
s
ettings
Sample Rate A-Net Slots Available
44.1/48kHz 64
88.2/96kHz 32
176.4/192kHz 16
In an all‑analog network, the sample rate can be set at the Control Master to
the following:
44.1kHz •
48 • kHz
88.2 • kHz
96 • kHz
176.4 • kHz
192 • kHz
When an external clock is used with a Pro64 digital I/O device, the system
can lock to any sample rate within the range that is shown in the table below.
No sample rate converters are ever required when using an external clock.
When using an external clock the Sample Rate display on the 6416m and all
other Pro64 I/O modules will light the LED corresponding to the rate closest
to the incoming clock rate.
Pro64 Series Supported Sample Rates
Sample Rate Minimum Maximum
1x 44.1/48kHz 39.7kHz 52kHz
2x 88.2/96kHz 79.4kHz 104kHz
4x 176.4/192kHz 158.8kHz 208kHz
Changing the Sample Rate
The network sample rate can be changed only at the Clock Master. Changing
the sample rate is done with the selection button found below the Sample
Rate LED readout.
To choose a new sample rate when the 6416m is Clock Master, press the
selection button beneath the sample rate list. Pressing the button selects the
next sample rate in the list and immediately starts blinking the new rate’s
LED and the Enter/Cancel LED; confirmation is required. To confirm the new
sample rate, press the E
ntEr
button. To exit without changing the sample
rate, press C
anCEl
.
