Aviom 6416m/RCI/MCS - Manual (Page 126)

115 s
PeciFicAtions
RCI Specifications
Controller Port Front panel; EtherCon RJ45, Accepts MCS
Headphone Monitor 1/4‑inch TRS, mono, with level control
Monitor Output XLR jack, balanced line level, mono
XLR Output Pin 1: Shield; Pin 2: Hot; Pin 3: Cold
XLR Output Pad 21dB
XLR Max. Output Level +4dBu (Pad off), ‑17dBu (Pad on);
rear‑panel switch
Max. Ambient Temp. 50°C
A-Net 2 EtherCon RJ45 connectors
A-Net Cable Length 400 feet (120 meters) Cat‑5e between
devices
Power Supply 100‑240VAC, 50‑60Hz, 16W
Internal switching type; IEC connector
Backup DC Power 24VDC +/‑5%, 0.55A typical, 1.A max.
4‑pin XLR
Pin 1: Ground; Pin 2/3: no connect; Pin 4:
24VDC
Dimensions 1U: 19"w x 8"d x 1.75"h (482.6 x 203 x 44
mm)
Weight 7 pounds (3.17 kg)
