Mcs specifications – Aviom 6416m/RCI/MCS User Manual
Page 129
118
s
PeciFicAtions
MCS Specifications
Controller Port
EtherCon RJ45, Connects to RCI
Channel Level
64 bicolor LEDs
High Resolution Meter
10‑segment, ‑48 to 0dB
Peak Hold
On/Off
Gain Control
Rotary, per channel, in 1dB steps
Channel Controls
Phase On/Off
Low Cut Filter On/Off
24dB Pad On/Off
+48V Phantom Power On/Off
Mute On/Off
Preset Management
Save/recall 16 presets; stored in the 6416m
Mic Input Module
Cable Length between
the RCI and MCS
400 feet (120 meters) Cat‑5e between
devices
Dimensions
6"w x 5"d x 1.5"h (152.4 x 127 x 38.1 mm)
Weight:
2 pounds (0.91 kg)
