6416m Front Panel Components
1. A‑Net LED
2. Control Master LED
3. VDC Slot and Port Configuration
4. Managed Mode Button
5. Edit Lock Button
6. Enter/Cancel Buttons and LED
Gain Knob and Readout
7.
Phase, Low Cut, Pad, and +48V Buttons
8.
