111 s
PeciFicAtions
6416m Specifications
Channels 16 inputs Mic‑ or line‑level
XLR Inputs Pin 1: Shield; Pin 2: Hot; Pin 3: Cold
Passive Splitter/
Alternate Inputs
DB25 multipin; audio pinout
Differential Input
Impedance
3.6k ohms
Input Gain Range 0–55dB, variable, in 1dB increments
Maximum Input Level
resulting in 0dBFS
0dB gain, Pad on = +24dBu
0dB gain, Pad off = 0dBu
55dB gain, Pad on = ‑31dBu
55dB gain, Pad off = ‑55dBu
Pad ‑24dB, switchable per channel
Low Cut Filter Per channel; ‑3dB @ 85Hz, 18dB per octave
Phantom Power +48V, individually selectable per channel
Preset Memory 16; saves all channel strip audio parameters
Sample Rates 1x: 39.7–52kHz;
2x: 79.4–104kHz;
4x: 158.8–
208kHz
24‑bit resolution
Frequency Response +/‑ 0.3dB 20‑23kHz at 48kHz
+/‑ 0.3dB 20‑45kHz at 96kHz
+/‑ 0.3dB 20‑53kHz at 192kHz
‑3dB @ 2Hz (at all sample rates)
THD +N 0.0015% @ 1.0kHz, ‑10dBFS
0.007% @ 1.0 kHz, ‑1dBFS
Dynamic Range
(noise floor)
112dB
Crosstalk ‑110dB @ 1kHz, 35dB gain
Equivalent Input Noise
(EIN)
‑127dBu
CMRR (common mode
rejection ratio)
78dB @ 1.kHz / 75dB @ 10kHz, typical
