Cutting from Below the Bushing Holder
The SC-5 Sure Cut Servo Cutter housing maximizes versatili-
ty and operational ease. Due to the size of the flywheel it was
determined best to mount it directly below the bushing holder
keeping the center of gravity low and offering the following
benefits:
● Accessibility of the flywheel for ease of blade changes.
● Built in blade lubrication tray can be integral to the design
of the cutting chamber.
● An optional blade heating system can be added to give
optimum versatility to this cutter.
● With the bushing holder above the flywheel tremendous
cutting capacity is available without extreme blade length.
● Ease of discharge conveyor interface for part support and
automatic ejection systems is made simple with this layout.
● The optional slide system can enable the use of rigids and
flexibles.
To get the full benefit from the servo cutter Conair has provid-
ed several cutting modes, see Cutter Control, Section 4. The
Conair SC-5 Sure Cut servo rotary knife cutter is a truly inno-
vative cutter. Loaded with features and backed up by the most
extensive service support system in the industry.
