A.11 Comfort Plus Commercial Hydronic
System Low Voltage Wiring Diagram - Model 7120 with Variable Speed
The "R" and "C" positions in the low voltage terminal
strip may be used as a source of 24 VAC for powering
external low voltage devices (60 VA maximum).
