5. PROBLEMSOLVING

Clearing a Recording Paper
Jam

If the recording paper becomes jammed in the machine, the display will

show information code 001 or 002. To clear the jam, open the RCV Cover
and remove the jammed recording paper as shown in the figure below.
Then reset the recording paper following the loading procedure on page

2-5.

RCV Cover

Latch Button

If you cannot remove the jammed recording paper easily, turn the Blue

Cam Wheel in the arrow direction until it stops with a click. Then remove

the paper.

Cutter Unit

Blue Cam Wheel
