Using the Control Panel
Protocol Select
ON .....................X/ON-X/OFF Protocol
OFF* * ............... DTR Protocol
@
Remaining Buffer Capacity to Suspend
Data Transfer (S.D.T.) (X/OFF)
ON* ................... 128 byte
OFF ................... 512 byte
Remaining Buffer Capacity to Resume
Data Transfer (R.D.T.) (X/ON)
— When the S.D.T. is set to ON
ON* ................... 256 byte
OFF ................... 384 byte
— When the S.D.T. is set to OFF
ON* ................... 640 byte
OFF ................... 768 byte
Designation of Signal Polarity for DTR
Protocol Mode
NO................... . When the signal is
“space”, the printer tells
the computer that it can-
@
not accept transferring
data.
OFF* ............... . When the signal is
“mark", the printer tells
the computer that it can­
not accept transferring
data.
Note:
• Items ® ~
L
will only appear when the
optional KX-PS14 serial interface board is
installed.
* denotes setting when shipped from factory.
CO
The control table is replaced with the following table.
Column indicator
Row indicator
Cl C2 C3 C4 C5
CD CD CD CD CD 1—1
R1 C=1
R2
czt
R3 dJ
R4
CD
SUPER
QUIET
/----------- \
TEAR
OFF
/ ' >
LOAD
PARK
f ' >
ON LINE
(------------\
FF
f ---------- \
LF
^
___________> L--------- j V______ / V______ 4
Note:
• The rightmost column indicator is ignored.
• Each indicator is controled by using the keys below.
