:ÉÌliiÌÌÌiÌ

Basic connections (for supplied accessories)

For Australia and N.Z.

The configuration of AC mains lead and FM antenna terminal are
different.

AC power supply cord

Plug the cord into an outlet only after
ail other connections have been
made.

AM loop antenna

1. Attach the antenna holder to

the rear panel. Press the an*
tenna holder hard enough to
get it fixed firmly in place, with

a click.

2, Clamp the antenna to the an

tenna holder.

3. Connect the antenna terminal

to the rear panel of the unit.

4. While listening to an MW (AM)

broadcast, position the loop
antenna for the best reception.
