AMPLIFIER SECTION

1 kHz continuous power output,
Both channels driven

DIN

2X35

W (THD 1 %, 6Q)

RMS (1 kHz) 2x50 W (THD 10%, 6£1)

Input sensitivity

AUX

250 mV

Input impedance

AUX

22 kQ

FM TUNER SECTION

Frequency range

87.50-108.00 M Hz

Sensitivity 23.3 dBf (4.0 pV. IHF ’58)

Antenna terminai(s) 75Q (unbalanced)

AM TUNER SECTION

Frequency range

(For United Kingdom)

MW

522-1611 kHz

LW

144-288 kHz

(For Australia and N.Z.)
AM

522-1611 kHz

Sensitivity (S/N 20 dB)

MW (AM)

500 pV/m

CASSETTE DECK SECTION

Track system

4 track, 2 channel

Meads

Record/playback Solid permalloy head
Erasure

Double gap ferrite head

SPEAKER SECTION

(For United Kingdom)

Motor
Recording system
Erasing system
Tape speed

Frequency response

NORMAL
HIGH

S/N

Dolby NR off

Dolby NR on

Wow and flutter

DC servo motor

AC bias 100 kHz

AC erase

4.8 cm/s

35 Hz-14 kHz
35 Hz-14 kHz

50 dB (A weighted)

60 dB (CCIR)

0.18% (WRMS)

Fast forward and rewind times

/^prox. 120 seconds

with C-60 cassette tape

CD SECTION

Sampling frequency

44.1 kHz

Decoding

16 bit linear

Beam source/wave length

Semiconductor laser/780 nm

Number of channels

Stereo

S/N

SP OUT

85 dB (JIS.A)

Wow and flutter Below measurable limit
Digital filter

8 fs

D/A converter

MASH (1 bit DAC)

Type

Speaker(s)

Woofer
Midrange
Tweeter

Impedance
Input power

3 way speaker system

14 cm cone type

6 cm cone type

Piezo type

60

80 W (Music)

40 W (DIN)

Output sound pressure level

86 dB/W(1.0 m)

Cross over frequency

1.5 kHz, 10 kHz

Frequency range 45 Hz-22 kHz (-16 dB)

52 Hz-20 kHz (-lOdB)

Dimensions (WXHXD) 230x345x251 mm
Weight

3.3 kg

(For Australia and N,Z.)
Type

Speaker(s)

Woofer

Midrange

Tweeter

Impedance
Input power

3 way speaker system

17 cm cone type

6 cm cone type

Piezo type

6C

160 W (Music)

80 W (DIN)

Output sound pressure level

87 dB/W(1.0 m)

Cross over frequency

1.5 kHz, 10 kHz

Frequency range 43 Hz-22 kHz (-16 dB)

50 Hz-20 kHz (-10 dB)

Dimensions (WXHxD) 230x345x251 mm
Weight

3.5 kg

GENERAL

Power consumption

130 W

Power supply AC 50 Hz, 230-240 V
Dimensions

(WXHXD)270x347x424

mm

Weight

10.7 kg

Notes:

1. Specifications are subject to change

without notice.
Weight and dimensions are

approximate.

2. Total harmonic distortion is measured

by the digital spectrum analyzer.

MASH is a trademark of NTT.
