Electrical Connections
Caution:
• This product is designed to operate with a 12 V
DC, negative ground battery system.
• To prevent damage to the unit, be sure to follow
the connection diagram below.
• Remove approximately W' {5 mm) of protective
covering from the ends of the leads before con
necting.
• Do not insert the power connector into the unit
until the wiring is completed.
• Be sure to insulate any exposed wires from a
possible short-circuit from the car chassis.
Bundle all cables and keep cable terminals free
from touching any metal parts.
• Remember, if your car has a drive computer or a
navigation computer, the data of its memory
may be erased when the battery terminals are
disconnected.
□ Wiring Diagram
Antenna
External amplifier control power lead^4-—
(max. 500 mA) .
This lead is for connection to the power amplifier.
{Blue/wtiite stripe)
Note:
This lead is used for power control when an external power amplifier
is connected. The power supply of a power amplifier will be activated
when turning on the power of this unit.
Dual CD changer control lead
Note:
Insulate this lead with vinyl tape when you do not connect it.
(Brown/white stripe)
Antenna control lead
^
-----------
(to motor antenna) (max. 500 mA)
This lead is not intended for use with switch actuated power
antenna.
(Blue)
Note:
The power antenna extends automatically
when the AM/FM radio mode is selected.
ACC power lead <—
To ACC power, +12VDC,
ACC
(Red)
Battery lead
^
---------------
To the battery, continuous -t-12 V DC.
BATTERVI 5
(Yellow)
Ground lead
^
---------------------
To a clean, bare metallic part of the car chassis.
(Black)
