Installation Guide
WARNING
This installation information is de
signed for experienced installers and is
not intended for non-technical individu
als. It does not contain warnings or cau
tions of potential dangers involved in
attempting to install this product.
Any attempt to install this product in a
motor car by anyone other than quali
fied installer could cause damage to the
electrical system and could result in se
rious personal injury or death.
□ Installation Hardware
No.
Item
Diagram
Q’ty
©
Mounting collar
1
CD
Hex. nut (5 mm0)
1
(3)
Rear support strap
1
©
Tapping screw
(5 mm0x16 mm)
1
Mounting bolt (5 mm0)
1
CD
Power connector
✓
1
CD
Removable face plate
case
1
CD
Trim plate
1
CD
Mounting spring (R)
1
©
Mounting spring (L)
1
0
Flat-head screw
(5 mm0x6 mm)
2
0
Lock cancel plate
'O
2
□ Overview
This product should be installed by a professional.
However, if you plan to install this product yourself,
your first step is to decide where to install it.
The instructions in these pages will guide you
through the remaining steps:
(Please
refer
to
the
“WARNING”
statement
above.)
• Identify and label the car wires.
• Connect the car wires to the wires of the power
connector.
• install the unit in the dashboard.
• Check the operation of the unit.
If you encounter problems, please consult your
nearest professional installer.
Caution:
• This unit operates with a 12 V DC negative
ground auto battery system only. Do not at
tempt tO/iise it in any other system. Doing so
could cause serious damage.
Before you begin installation, look for the items
which are packed with your unit.
• Warranty Card.
..Fill this out promptly.
• Panasonic Servicenter List for Service Directory
...Keep for future reference in case the product
needs servicing.
• Installation Hardware..
Needed for in-dash in
stallation.
□ Required Tools
You’ll need a screwdriver, a 1.5 V AA battery, and
the following:
Electrical
Side-cut
tape
pliers
12 V DC
Test bulb
