Panasonic SL-CT350 - Manual

Audio (CD-DA)
Sampling frequency:
44.1 kHz
No. of channels: 2 (left and right, stereo)
Frequency response:
20 Hz to 20,000 Hz (i0.5 dB to j7 dB)
Headphone output level:
RMS max. 6 mWi6 mW/16 ≠ (adjustable)
Pickup
Light source:
Semiconductor laser
Wavelength: 780 nm
(NORSK)
Bølgelengde
780 nm
Laserstyrke
Ingen farlig stråling sendes ut
(med sikkerhets-beskyttelse)
General
Power supply:
DC input (via AC adaptor, not included):
DC 4.5 V
DC input (via included AC adaptor):
DC 4.5 V
AC adaptor input:
(The United Kingdom)
AC 220 –240 V 50/60 Hz
(Continental Europe)
AC 220 –230 V 50/60 Hz
(Australia and N.Z.)
AC 230 –240 V 50 Hz
(Sets purchased in Japan)
AC 110 –127 V/ 220 –240 V 50/60 Hz
Power consumption:
Using AC adaptor: 0.8 W
Recharging: 3.0 W
Play time:
Using on a flat stable surface at
25 eC, EQ is off, Hold is on and
Anti-skip is on POS 1 (CD-DA). Play
times are in hours and approximate.
Recharging time: About 3.5 to 4.5 hours
≥The play time may be less depending
on the operating conditions.
≥Play time will be considerably
reduced when playing CD-RW.
Dimensions (WaHaD):
136.7 mma21.5 mma136.7 mm
Mass: 180 g (with batteries)
157 g (without batteries)
Operational temperature range:
0 eC–40 eC
Rechargeable temperature range:
5 eC–40 eC
Note:
Specifications are subject to change
without notice.
Mass and dimensions are approximate. SL-CT352 SL-CT350
SL-CT352 SL-CT350
SL-CT345
Batteries
used
2 alkaline batteries (LR03)
2 alkaline batteries (LR6)
4 alkaline batteries
(2 LR03r2 LR6)
2 optional rechargeable batteries
(Europe: HHR-4AGE/2B
Other areas: HHR-4AGT/2B)
2 optional rechargeable
(Europe: HHR-4AGE/2B
Other areas: HHR-4AGT/2B) and
2 alkaline (LR6) batteries
No play.
No sound or there
is a lot of noise.
Play doesn’t resume
from the track where
play stopped at.
Play doesn’t start
from the first track.
Cannot specify point A or B.
Cannot change the
anti-skip mode.
The unit malfunctions
when connected to
other equipment.
Cannot hear the remote
control’s operation tone.
The remote control
does not work properly.
Cannot recharge.
The AC adaptor becomes
warm during recharging.
SL-CT352
Play
time
26
60
86
16
76
The batteries are taking
a long time to recharge.
Play time is short
after recharging.
The battery indicator
fails to appear or is
incorrect.
The unit stops working.
Power cuts off.
(
)
*
'
1
≥The HOLD function is on. Cancel HOLD ( ➪page 4).
≥The batteries may be depleted ( ➪page 3).
≥The disc isn’t correctly set.
≥The disc is scratched or dirty. (Tracks may be skipped.)
≥
There is moisture on the lens. Wait for about an hour and then try again.
≥The lens is dirty: clean it with a blower (recommended
product: SZZP1038C). If the lens gets marked with
fingerprints, gently wipe them off with a cotton swab.
≥Ensure the plugs are inserted firmly.
≥Wipe the plugs with a clean cloth.
≥The disc is scratched or dirty.
≥The elapsed play time disappears and sound is
interrupted if bumps continue repeatedly.
≥This doesn’t work during random play.
≥It may not work correctly under some conditions.
≥Random play modes may be on ( ➪page 4).
≥ Play resumes from the track where you last stopped play
(
➪page 4, Play). (If the lid is opened while the unit is
turned off, the resume function may not be cancelled.)
You may not be able to specify point A or B at the end of a disc.
If [:] or [9] is pressed before [MEMO] you
cannot change the mode.
Be sure to connect other equipment through the remote
control. If speakers are connected directly to the unit,
they should have an impedance of 1 k≠ or less.
The operation tone may be turned off ( ➪page 4).
≥Remove the plug and reinsert it as fully as possible.
≥Use only the included remote control to operate the unit.
≥You aren’t using the special rechargeable batteries ( ➪page 3).
≥You must insert two batteries before you can charge.
≥The unit must be off before you can charge.
This is normal.
SL-CT345
SL-CT350
SL-CT352
Dear
Customer
Thank you for
purchasing this
product.
Before connecting,
operating or
adjusting this
product, please
read these
instructions
completely. Please
keep this manual
for future reference.
RQT7830-B
F1104SZ0
GN SG EB EG p
Operating Instructions
Portable CD Player
Note:
“EB” on the packaging
indicates the United
Kingdom.
Matsushita Electric Industrial Co., Ltd.
Web Site: http://www.panasonic.co.jp/global/
Troubleshooting guide
References to the remote control apply only to SL-CT352.
Before requesting service, make the following checks. If you are in doubt about some of the check points, or if the solutions indicated in the chart do not solve the
problem, consult your dealer for instructions.
The batteries may take as long as 4.5 hours to recharge
under some conditions.
≥This may occur the first time you charge the batteries
or if you haven’t used them for a long time. Play time
should be restored after a few recharges.
≥The batteries can go flat if you leave the AC adaptor
connected after charging is complete.
≥If play is extremely short even after fully recharging the
batteries, the batteries may have exceeded their life
(Rechargeable batteries can be recharged
approximately 300 times). Please purchase new
nickel-metal hydride rechargeable batteries (Europe:
HHR-4AGE/2B Other areas: HHR-4AGT/2B).
≥ The indicator does not appear when the AC adaptor is connected.
≥The indicator may not appear correctly when using the
rechargeable and dry cell batteries at the same time and under
certain conditions.
Disconnect then reconnect all power sources (batteries and AC adaptor).
If you connect or disconnect the AC adaptor, the power
cuts off even if the batteries are inserted.
Specifications
Display
The HOLD function is on. Cancel HOLD ( ➪page 4).
≥You haven’t inserted a disc or it isn’t inserted correctly.
≥You have inserted a disc this unit cannot play.
The disc lid is open.
The program already contains 20 tracks.
Maintenance
If the surfaces are dirty wipe with a soft, dry cloth.
≥Never use alcohol, paint thinner or benzine to clean this unit.
≥
Before using chemically treated cloth, read the instructions that came with the cloth carefully.
