□ Installation Procedures
First complete the electrical connections, and then
check them for correctness, {page 70)
Engage the mounting
springs (^) in the
mounting
holes
of
the mounting collar
® firmly.
@— Mounting
hole
Mounting springs
(a) Using the rear support strap @
Fire wall of car
(4) Tapping screw
3 mm0
CD Hex. nut
@ Rear support
strap
(5) Mounting bolt
Mounting collar
The
included
mounting
collar
0
is
designed
specifically for this unit. Do not use it to attach
any other model.
Insert mounting collar
0
into the dash
board, and bend the mounting tabs out
with a screwdriver.
The tabs to be bent vary depending on the
car. To securely install the unit, fully bend a
number of the tabs so that there is no rattling.
Example:
Attach the mounting springs (D, ® to the
unit.
Secure the rear of the unit.
After fixing mounting bolt (§) and power con
nector d), fix the rear of the unit to the car
body by either method
(a)
or
(b)
shown below.
Insert trim plate (§).
0
After
installation,
recon
nect the negative
0
bat
tery terminal.
(b) Using the rubber cushion (option)
Rear support bracket
Rubber cushion (option) (provided on the car)
d) Mounting bolt
^ 0 Mounting collar
