AMPUFIER SECTION
1 kHz continuous power output, both
channels driven
DIN 2X20 W {THD 1 %, 6Q)
RMS 2X25 W (THD 10%, 6Q)
Total harmonic distortion
Half power at 1 kHz 0.07% (6Q)
Frequency response
AUX 60 Hz^20 kHz (-3 dB)
Input sensitivity and impedance
AUX 250 mV, 22 kQ
Tone controls
6-EQ SPACE modes
HEAVY, CLEAR, SOFT,
DISCO, LIVE, HALL
V.BASS (volume at -30 dB) 63 Hz, 7 dB
Load impedance
6Q
FM TUNER SECTION
Freq uency range 87,5-108 MHz
Sensitivity 23.3 dBf (4.0 pV, IHF ’58)
Total harmonic distortion
MONO 0.3%
STEREO 0.5%
S/N
MONO 60 dB (66 dB, IHF)
Antenna terminai(s) 750 (unbalanced)
AM TUNER SECTION
Frequency range
(For United Kingdom)
MW
LW
(For Others)
AM
Sensitivity (for 500 mW)
(For United Kingdom)
MW (at 999 kHz)
LW (at 252 kHz)
(For others)
AM (at 999 kHz)
522-1611 kHz
144-288 kHz
522-1611 kHz
250 tiV/m
500 nV/m
250 MV/m
CASSETTE DECK SECTION
Track system 4 tracks, 2 channels
Heads
Record/ptayback Solid pemrialloy head
(Rotary head)
Erasure Double gap ferrite head
Motor DC servo motor
Recording system AC bias 100 kHz
Erasing system
AC erase 100 kHz
Tape speed 4.8 cm/s
Frequency response
[(+3 dB, —6 dB) at deck out]
NORMAL
35 HZ-14 kHz
S/N 50 dB (A weighted)
Wow and flutter 0.18% (WRMS)
Fast forward and rewind times
Approx. 120 seconds
with C-60 cassette tape
CD SECTION
Sampling frequency 44.1 kHz
Decoding 16 bit linear
Beam source/wave length
Semiconductor laser/780 nm
Number of channels
Frequency response Stereo
20 Hz-20 kHz
(+1 dB, -2dB)
S/N
SP OUT
Wow and flutter
Digital filter
D/A converter
85 dB (JIS.A)
Below measurable limit
8fs
MASH (1 bit DAC)
SPEAKER SECTION
Type
Speaker(s)
Woofer
Tweeter
Impedance
Input power
(For United Kingdom)
(For others)
2 way 1 speaker, bass-ref
12 cm cone type
6 cm cone type
6Q
40 W (music)
20 W (DIN)
80 W (music)
40 W (DiN)
Output sound pressure level
85 dBAW(1.0 m)
Cross over frequency 8 kHz
Frequency range
47 Hz-22 kHz (-16dB)
54 Hz-20 kHz (-lOdB)
Dimensions (WXHXD)
200x345x207 mm
Weight 2 9 kg
GENERAL
Power supply AC 50 Hz, 230-240 V
Power consumption
100 W
Dimensions (WxHxD)
270X347X424 mm
Weight 9.7 kg
Notes:
1. Specifications are subject to change
without notice.
Weight and dimensions are approximate.
2. Total harmonic distortion is measured
by the digital spectrum analyzer.
MASH is a trademark of NTT.
