Description of Each Section
Caution
Be careful of hot air flowing out of the air exhaust
vents.
A
Your hand or face might suffers form burns if you
being them near the ventilation holes. Objects if
placed near these holes are liable to be deformed.
Air Exhaust Vents
Front
Adjuster Button
Used to adjust the tilt of the
projector.
Adjustable tegs.
Used to adjust the tilt of the projector.
Air Filter Section
RGB IN
© <§>
10
RGB input Terminal
Inputs the RGB signals
(PC picture signals)
(D sub-pin 15 input).
S-Video Input Terminals
Input terminal for the S-Video Signals
The S-Video takes priority when both
video input terminals are connected at
the same time.
I Video Input Terminals
These are the input terminals for the
video signal.
, Audio Input Terminals for Video
Input
These are the audio input terminals that
correspond to the S-Video and Video
Signals Since the projector has an
internal monaural speaker, audio signals
input in stereo (left and right) are
combined in the projector into a
monaural sound.
