Appendix: Summary of status icons
Appendix: Summary of status icons
The following Status Icons are
supported by the sensor during static
and kinematic measurements.
Position / accuracy status
Navigation (<100m)
When no icon is shown no position is
available. This usually means that no
(or not enough satellites) are tracked.
Other accuracy levels are not
supported unless realtime corrections
are received through a radio.
Position mode
Static - the GPS Antenna
should be held stationary.
Moving - The GPS Antenna
may move.
Number of visible satellites
The number of theoretically visible number of satellites according to the
currently used almanac is displayed.
Number of satellites used on L1 and L2
The number of currently tracked satellites are shown.
If a SR510 single frequency sensor is used only the L1 line is active.
