Basic GPS Operation
4-54 Effective Date 3/94 006-08751-0000 Rev 0
Basic GPS Operation
Chapter 4
4.12.2.2. The VOR 2 Page
See figure 4-174.
Line 1: The VOR identifier,
preceded by an arrow if it is the
active waypoint.
Line 2: The published magnetic station declination of the VOR.
Magnetic station declination is another way to say the published
magnetic variation for the VOR.
Line 4: The magnetic bearing to or the magnetic radial from the
VOR and the distance in nautical miles. Placing the cursor over the
radial/bearing field and pressing
E
toggles between radial from
and bearing to station.
4.12.3. NDB PAGES
Two pages of information may be displayed for each NDB in the
KLX 135. Sample NDB pages are shown in figures 4-175 through
4-177.
4.12.3.1. The NDB 1 Page
See figure 4-175.
Line 1: The NDB identifier,
preceded by an arrow if it is the
active waypoint. To the right of the
identifier is the frequency of the
NDB in kilohertz.
Line 2: The name of the NDB.
Lines 3-4: The latitude and longitude of the NDB
If the NDB is being viewed as part of the nearest NDBs list (see
section 4.7.3 ), the NDB 1 page format will differ as follows (see
figure 4-176):
Line 1: After the NDB identifier, the
number designating the NDB’s
position in the nearest NDB list is
displayed. In figure 4-176, DFI is
the nearest NDB.
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 DFI 1 246
136.97 DEFIANCE
>Leg
NDB 1 >021°To 2.3nm
Figure 4-176
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 MEX
136.97 Mag Var E 8°
>Leg
VOR 2 >359°To 97.7nm
Figure 4-174
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 DFI 246
136.97 DEFIANCE
>Leg N 41°20.07'
NDB 1 W 84°25.62'
Figure 4-175
