4.11.2. THE NAVIGATION 2 (NAV 2) PAGE
The NAV 2 pages in figures 4-155
and 4-156 display the aircraft’s
present position in one of two
formats. The first line is a cyclic field
which allows you to toggle between
formats. When the KLX 135 is first
powered up, it defaults to present
position in terms of the radial and
distance from a nearby VOR. You
can change the reference waypoint
from the nearby VOR to any
waypoint.
To change the NAV 2 page present position reference waypoint:
1. With the NAV 2 page on the
radial and distance from a
reference waypoint format, turn
on the cursor (
B
) and move it
to the Ref: field (figure 4-157).
2. Use the right inner and outer knobs to enter the waypoint you
wish to use as a reference.
3. Press
F
. The waypoint page for the identifier just entered will
be displayed.
4. If this is the waypoint you intend-
ed, press
F again. The display
will return to the NAV 2 page
(figure 4-158).
NOTE: If you change the reference waypoint, change to a page
other than the NAV 2 page, then turn back to the NAV 2 page, the
reference waypoint will revert back to a nearby VOR.
By turning on the cursor ( B ) over the first line and pressing E ,
you can change to the latitude and longitude format.
KLX 135 Pilot’s Guide Basic GPS Operation
4-47 Effective Date 3/94 006-08751-0000 Rev 0
Basic GPS Operation
Chapter 4
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg Ref:
KMKC
NAV 2 219°Fr 22.2nm
Figure 4-158
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg N 38°53.74'
NAV 2 W 94°53.39'
Figure 4-155
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg Ref: OJC
NAV 2 310°Fr 9.5nm
Figure 4-156
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 >Present Posn
136.97
>Leg Ref:
OJC
NAV 2 346°Fr 28.6nm
Figure 4-157
