If the airport is being viewed as part of
the
nearest airports list (see
section
4.7.3
, “Nearest and Complete
Waypoint Scan Lists”), the APT 1
page format will differ as follows (see
figure 4-163):
Line 1: After the airport identifier, the number designating the air-
port’s position in the nearest airport list is displayed. In figure 4-163,
KSZL is the third nearest airport.
Line 2: Same as a normal APT 1 page.
Line 3: Blank
Line 4: The magnetic bearing to or the magnetic radial from the
airport and the distance in nautical miles. Placing the cursor over the
radial/bearing field and pressing
E
toggles between radial from and
bearing to the airport.
4.12.1.2. THE AIRPORT 2 (APT 2) PAGE
See figure 4-164.
Line 1: The ICAO identifier (see
section 2.3
) of the airport; an arrow
precedes the identifier if it is the active
waypoint.
Lines 2-3: The latitude and longitude of the airport reference point
(the “official” location of the airport).
Line 4: The magnetic bearing to or the magnetic radial from the air-
port and the distance in nautical miles. Placing the cursor over the
radial/bearing field and pressing
E
toggles between radial from and
bearing to the airport.
If the airport is being viewed as part of
the
nearest airports list (see
section
4.7.4
, “‘Nearest’ and ‘Complete’
Waypoint Scan Lists”), the APT 2
page format will differ as follows (see
figure 4-165):
Line 1: After the airport identifier, the number designating the air-
port’s position in the nearest airport list is displayed.
Line 2: The city where the airport is located.
Basic GPS Operation
4-50
Effective Date 3/94 006-08751-0000 Rev 0
Basic GPS Operation
Chapter 4
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 KLIT 3
136.97 LITTLE ROCK
>Leg AR
APT 2 >103°To 14.5nm
Figure 4-165
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 KLIT 3 260ft
136.97 ADAMS
>Leg
APT 1 >103°To 14.5nm
Figure 4-163
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 KLIT
136.97 N 34°43.74'
>Leg W 92°13.47'
APT 2 >103°To 14.5nm
Figure 4-164
