Basic GPS Operation
4-48
Effective Date 3/94 006-08751-0000 Rev 0
Basic GPS Operation
Chapter 4
4.11.3. THE NAVIGATION 3 (NAV 3) PAGE
The Navigation (NAV) 3 page shows
you several important times pertaining
to your flight (figure 4-159).
Line 1: The current system time zone
and time. The time zone may be
changed by turning the cursor (
B
) on over it and turning the right
inner knob. All times shown on the NAV 3 page are in terms of the
system time zone (except for the flight time, which is an elapsed
time).
Line 2: The time of departure. This is the time when a valid ground-
speed was first greater than 30 knots (typically during takeoff).
Line 3: Estimated time of arrival at your destination. If the active
waypoint is not part of the active flight plan, the active waypoint will
be the destination. Otherwise, the last waypoint in your active flight
plan will be the destination.
Line 4: The elapsed flight time, which will be the hours and minutes
since the departure time.
4.11.4. THE NAVIGATION 4 (NAV 4) PAGE
The NAV 4 page (figure 4-160) shows
some supplemental navigation data.
Line 1: The active waypoint or leg,
just like the NAV 1 page.
Line 2: The present desired track (Dtk). This is the great circle
course between two waypoints. Any CDI or HSI driven by the
KLX 135, including the CDI displayed on the NAV 1 page, is
referenced to this desired track. You may wish to look at the
navigation terminology diagram in
Appendix A
at this time if you are
unfamiliar with terms like desired track and actual track.
NOTE: If the KLX 135 is in the OBS
mode, the selected course (Obs) is
displayed instead of the desired track
on the NAV 4 page (figure 4-161).
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 KICT ∆ KMCI
136.97 Obs 045°
>045 Track 046°
NAV 4 Brg 050°
Figure 4-161
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 KICT ∆ KMCI
136.97 Dtk 051°
>Leg Track 046°
NAV 4 Brg 050°
Figure 4-160
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 Time CDT 1605
136.97 Depart 1343
>Leg ETA KIXD 1710
NAV 3 Flight 2:22
Figure 4-159
