4.10.3. VIEWING THE WAYPOINT PAGES FOR THE ACTIVE
FLIGHT PLAN WAYPOINTS
The waypoint pages for each of the waypoints in the active flight plan
may be easily displayed by selecting the Active (ACT) Waypoint page
type. When the ACT page type is
first selected, the waypoint page for
the active waypoint will be displayed
(figure 4-132). The location of the
waypoint in the flight plan (waypoint
1, waypoint 2, etc.) is annunciated
with a number to the left of the
identifier. In addition, an arrow to the left of the waypoint number
designates the active waypoint. If there is a letter to the far right of
the identifier, it designates the type of
waypoint: A = airport, U = user-
defined waypoint. If the waypoint is a
VOR or an NDB, the navaid
frequency is displayed in this area
(figure 4-133).
To view the waypoints in the flight plan that are not the active
waypoint:
1. Pull the right inner knob to the
“out” position and turn it to view
each of the waypoints in the
order they are contained in the
flight plan (figure 4-134).
2. Once the desired waypoint is
found, the right inner knob may
be pushed back to the “in”
position and rotated to display
any of the other waypoint pages
(figure 4-135).
3. Pulling the knob back out will allow further scanning of the
waypoint pages in the active flight plan.
4.10.4. COMBINING DIRECT TO AND FLIGHT PLAN
OPERATION
It is very common when using flight plan operation to use the Direct
To function to proceed directly to a waypoint which exists in the
active flight plan. For example, after takeoff on an IFR flight plan, it is
KLX 135 Pilot’s Guide Basic GPS Operation
4-41 Effective Date 3/94 006-08751-0000 Rev 0
Basic GPS Operation
Chapter 4
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 ∆ 6 KPIH A
136.97 POCATELLO REGL
>Leg POCATELLO
ACT 1 ID
Figure 4-132
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 ∆ 5 PIH 112.60
136.97 POCATELLO
>Leg N 42°52.22'
ACT 1 W112°39.13'
Figure 4-133
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 1 KPVU A
136.97 PROVO MUN
>Leg PROVO
ACT 1 UT
Figure 4-134
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
118.00 1 KPVU A
136.97 UNIC 123.05
>Leg UNIC 122.80
ACT+4 CTAF 122.80
Figure 4-135
